Specifications
Brand Name :
CH Refractories
Model Number :
CCM
Certification :
ISO
Place of Origin :
China
MOQ :
5 Ton
Price :
USD 200-1000 per Ton
Payment Terms :
L/C, T/T
Supply Ability :
5000 Ton per month
Delivery Time :
5-15 working days
Packaging Details :
25kg bag into jumbo bag
name :
low cement castable refractory material
Type :
Refractory castable
material :
low cement Castable
Shape :
Powder
Al2o3 content (%) :
65-85% or as requirements
Color :
Gray
Description

Refractory Castable Cement Alumina Castable High Alumina Cement

Refractory Castable Cement Alumina Castable

Corundum castable refractory is divided into cement-free corundum castable refractory and cement corundum castable refractory. Also there are different kinds of corundum castables refractory made by CH refractories company according to different raw material. For example, white fused alumina manufactured corundum castable refractory, brown fused alumina manufactured corundum castable refractory.

Casting method is usually used for construction, which can be either cast into a whole lining or cast into prefabricated blocks for splicing on site. Corundum castable is characterized by high strength, high softening temperature under load and good slag resistance. It is generally used at 1400~1600℃ and is mainly used in key parts of thermal kiln. Large volume density, generally above 2.8, large thermal conductivity, good heat transfer performance, suitable for high temperature environment with large temperature changes, this kind of castable can replace the use of high-quality high-charge soft high-aluminum brick;

Corundum castable refractory has good properties of high strength, good high temperature performance, stable volume, low thermal conductivity, strong resistance to slag penetration, erosion resistance, convenient construction, strong furnace structure.

Applications of Corundum Castable:
Steel furnace, cement kiln, glass kiln, iron making furnace, ceramic tunnel kiln and so on.

Item CH-GYJ85 CH-GYJ90 CH-GYJ93
AL2O3(%) 85 90 93
Sio2(%) 10 6 2
Bulk Density(g/cm3) 2.9 3.0 3.0

Cold Crushing Strength(Mpa)
110℃*24h 80 100 80
1100℃*3h 80 100 80
1500℃*3h 80 100 80

Cold Pressed Antisegregation Strength(Mpa)
110℃*24h 8 12 8
1100℃*3h 8 12 8
1500℃*3h 8 15 8
Hot after-line rate of change(%) 1100℃*3h -0.1~-0.3 -0.1~-0.3 +-0.2
Max Service temp(℃) 1650 -0.1~-0.5 -0.2~-0.6 +-0.5
Construction methods Vibration Vibration Vibration
Reference water volume(%) 5~6 5.5~6.5 5.5~6.5

Advantages of Corundum Castable:
High strength
High temperature resistance
Strong wear resistance
Good erosion resistance
Excellent thermal shock stability
