100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
Specifications
Brand Name :
HSF
Model Number :
CPE100W
Place of Origin :
China
MOQ :
1000kg
Price :
N.A.
Payment Terms :
T/T
Supply Ability :
50 tons per day
Delivery Time :
10 working days
Packaging Details :
Export Standard
Materials :
PE or Blended PE
Color :
White
Surface Finish :
double-sided glossy, one side matte one side glossy, or double-sided matte.
Thickness :
30μm~300μm
Web Width :
Up to 2600mm
Description
100μm White Cast PE Film
High-performance white cast polyethylene film offering exceptional flatness, tear resistance, and barrier properties. Ideal for surface protection, packaging, and industrial applications with stable thickness and easy processing.
Production Process
Manufactured using cast extrusion technology, this 100μm white CPE film combines PE resin, white masterbatch, and additives. The mixture is melted, extruded through a T-die, cast onto a chill roll for rapid cooling, then trimmed, thickness-tested, and wound into finished rolls.
Product Features
  • Uniform thickness and high flatness
  • Excellent optical properties and smooth surface
  • Superior tensile strength and tear resistance
  • Stable dimensional stability
  • Opaque white, non-transparent finish
  • Low moisture and vapor transmission rates
100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection 100μm Opaque White High Density Polyethylene Film with Tear Resistance for Industrial Packaging and Surface Protection
Key Advantages
  • Superior flatness compared to blown film
  • Stable processing for lamination and sealing operations
  • Reliable opacity and complete light blocking
  • Consistent quality in mass production runs
  • Cost-effective solution for industrial and packaging applications
Applications
  • Surface protection for panels and boards
  • Industrial packaging and component wrapping
  • Lamination and composite materials
  • Construction and moisture-proof protection
  • General industrial protective covering
Physical Properties
Test Item Unit Industry Standard Requirement (100μm White CPE) Our Product Standard Actual Test Result Qualification Judgment
Total Thickness of Base Film μm 100±10 100±6 99.4 (Pure LLDPE, uniform thickness distribution) Qualified
Whiteness Uniformity - No obvious color difference, uniform whiteness, no yellowing, no spots No color difference, uniform dispersion of white masterbatch, no yellowing, no spots, no color migration No color difference, uniform masterbatch dispersion, no yellowing, no spots, no color migration Qualified
Light Shielding Rate % ≥92.0 ≥94.0 94.7 Qualified
Tensile Strength (Longitudinal/Transverse) MPa ≥24/≥22 ≥26/≥24 26.5/24.8 Qualified
Elongation at Break (Longitudinal/Transverse) % ≥360/≥340 ≥380/≥360 385/367 Qualified
Heat Sealing Strength (122℃, 0.32MPa, 1s) N/15mm ≥13.0 ≥15.0 15.6 Qualified
Surface Tension (Corona Treated Surface) mN/m ≥36 ≥38 39.7 Qualified
Tear Resistance (Longitudinal/Transverse) N ≥18/≥16 ≥20/≥18 20.5/18.7 Qualified
Moisture Barrier Performance (23℃, 85%RH) g/(m²*24h) ≤5.2 ≤4.7 4.5 Qualified
Oil Resistance (Soaked in n-hexane for 24h) - No obvious swelling, discoloration or deformation No swelling, no discoloration, no adhesion, no masterbatch precipitation, no deformation, no oil penetration No swelling, no discoloration, no adhesion, no masterbatch precipitation, no deformation, no oil penetration Qualified
Hardness (Shore D) HD 57±5 57±3 56.9 Qualified
Weather Resistance (UV Aging for 72h) - No obvious yellowing, fading, cracking or discoloration No yellowing, no fading, no cracking, no deformation, whiteness retention rate ≥98.0% No yellowing, no fading, no cracking, no deformation, whiteness retention rate 98.8% Qualified
Environmental Protection Performance (Food Contact Grade) - Complies with GB 4806.7-2016 Complies with GB 4806.7-2016, no peculiar smell, no harmful precipitation, non-toxic white masterbatch, no heavy metal residues, no harmful substance release Complies with GB 4806.7-2016, no peculiar smell, no harmful precipitation, non-toxic white masterbatch, no heavy metal residues, no harmful substance release Qualified
