Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Specifications
Place of Origin :
Guangdong, China
Brand Name :
MSL
Model Number :
MSLCU71
Power Source :
Electric
Warranty :
1 Year
After-sale Service :
Online technical support
Material :
Metal, plastic
Shelf Life :
3 years
Quality Certification :
ce
Instrument classification :
Class II
Safety standard :
GB/T18830-2009
Brand :
Ovum Pick-Up Ultrasound System
model :
MSLCU71
Imaging Modes :
B/C/D triplex mode Dual live: B/C,B/PW,B/M Dual split: B/C, B/M, B/PW
Gray scale levels :
256
Transducer Type :
Convex Array,Linear Array,Endocavity Array
Transducer frequency :
2 to15 Mhz
Scanning depth :
up to 351mm
Monitor :
15' high resolution LCD monitor with tilting to view it freely
Ultrasound platform :
Based on Windows high speed hardware platform
Transducer element :
128
Description
Product Description
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Specification
item
value
Place of Origin
China
Guangdong
Brand Name
MSL
Model Number
MSLCU71
Power Source
Electric
Warranty
1 Year
After-sale Service
Online technical support
Material
Metal, Plastic
Shelf Life
3 years
Quality Certification
CE
Instrument classification
Class II
Safety standard
GB/T18830-2009
Brand
Ovum Pick-Up Ultrasound System
model
MSLCU71
Imaging Modes
B/C/D triplex mode Dual live: B/C,B/PW,B/M Dual split: B/C, B/M, B/PW
Gray scale levels
256
Transducer Type
Convex Array,Linear Array,Endocavity Array
Transducer frequency
2 to15 Mhz
Scanning depth
up to 351mm
Monitor
15' high resolution LCD monitor with tilting to view it freely
Ultrasound platform
Based on Windows high speed hardware platform
Transducer element
128
More details
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Standard Features:
Performance and features comparable to that of conventional cart‐based systems, PT60 point‐of‐care
color Doppler system, is a true simple smart in ultrasound, offers a new level of intuitive operation,
innovative productivity tools and powerful processing for empowering Point of Care(including
Anesthesiology),Emergency Medicine and General Imaging, Women's Health. The result is an all‐new
level of efficiency and image quality

Application scenarios:
* Applicable to different body scans, for example, Abdomen,Obstetrics,Gynecology,Cardiology,Small Parts,Urology,Kidney,MSK(Musculoskeletal);Carotid; Orthopedic; Vascular
* and varied user environment. Ultrasonography, emergency, operating room, ICU, ward and out‐call, etc

Multi‐frequency probes:
Convex probes C3.5/R60/D‐3 color Doppler convex array transducer(standard configuration)
---Applications:ABD, Renal, ABD‐Vascular, Ped‐ABD, GYN, OB, Fetal Heart, Urology, Prostate
Frequency Bandwidth: 2.0‐5.0MHz
Central frequency: 3.5 MHz
Radius: 60 mm
View angle: 61 degrees
Scanning Depth: 36‐351 mm
Element: 128
Biopsy guide available
PV6.5/10/64D‐3 color Doppler Micro‐convex array transducer
---Applications:Pediatric, fetal heart
Frequency Bandwidth: 4.0‐9.0 MHz
Center frequency: 6.5 MHz
Radius: 10 mm
View angle: 150 degrees
Scanning Depth: 36~184 mm
Element: 128
Biopsy guide available

EC6.5/10/64D‐3 color Doppler Trans‐vaginal probe
---Applications:Early OB, OB/GYN, Urology
Frequency Bandwidth: 4.0‐9.0 MHz
Center frequency: 6.5 MHz
Radius: 10 mm
View angle: 150 degrees
Scanning Depth: 36~184 mm
Element: 128
Biopsy guide available

Linear probes HL10.0/25/64D‐3 High Frequency color Doppler Linear probe

---Applications: Vascular,Carotid,P‐Arterial,SMP,Thyroid,Breast,Testicle,SmEye,MSK, ABD
Frequency Bandwidth:6.0‐14.0 MHz
Center frequency: 10.0MHz
Scanning width: 25 mm
Scanning Depth: 18~184 mm
Element: 128
Biopsy guide available

HL10.0/40‐64D‐3 color Doppler Linear probe
---Applications: Vascular,Carotid,P‐Arterial,SMP,Thyroid,Breast,Testicle,SmEye,MSK, ABD
Frequency Bandwidth: 5.0‐10.0 MHz
Center frequency: 7.5MHz
Scanning width: 40 mm
Scanning Depth: 18~184 mm
Element: 128
Biopsy guide available
Series products
Company Profile
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
Portable Vet Ultrasound Machine Veterinary Ultrasound Ovum Pick-Up Egg Collection Ultrasound Scanner
FAQ
1. who are we?
We are based in Guagndong, China, start from 2013,sell to Southeast Asia(18.00%),Africa(18.00%),North America(15.00%),South America(12.00%),Mid East(8.00%),Southern Europe(8.00%),Western Europe(6.00%),Central America(3.00%),South Asia(3.00%),Eastern Europe(2.00%),Oceania(2.00%),Northern Europe(2.00%),Domestic Market(2.00%),Eastern Asia(00.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Ultrasound Machine,X-ray,Hematology Analyzer,Chemistry Analyzer,Veterinary Equipment

4. why should you buy from us not from other suppliers?
Quality assured, payment safe, excellent after-sale service

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,German,Arabic,French,Russian,Korean,Hindi,Italian
