Specifications
Brand Name :
BAOLIDA
Model Number :
BLD-202068
Certification :
ISO9001:2008
Place of Origin :
Sichuan,China
MOQ :
Negotiation
Price :
USD 2-6/sqm
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500000 squre meters per month
Delivery Time :
15 word days
Packaging Details :
standard package
Product name :
150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame
Material :
hot dip galvanized steel
Length :
Customizable
width :
Customizable
color :
clear
Span Width :
6m/6.2m/6.4m/8m/9.6m/10.8m/12m
Ventilation :
Roof Ventilation/side Ventilation
Structure :
Stable Structure Easily Assembled
Characteristic :
Commercial greenhouse for agriculture
Application :
vegetables
Description

150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame

Tunnel Plastic Greenhouse Product describe:

Customizable, professionally produced greenhouses are customized according to the needs of users, covering materials of different sizes and thicknesses are determined according to the actual planting of plants by users.As long as the user tells us the requirements, we will design the greenhouse according to the requirements of the customer.The production time of customized greenhouse will be relatively long, and the cost will be relatively high, because special mold is needed to produce.

Dimension Related data
Length 60m or customized
Width 8m or customized
Top height 2.8m-4m
Shoulder height 1.5m-2.5m
Arch spacing 1.33m or customized
Arch diameter φ32mm
Arch thickness 1.5mm
Covering material PE film,
Basic equipment Framework,door,insect net,film
Foundation Insert the arch into the ground
Tube material Hot dip galvanized steel tubu
Thickness of PE film 150micron

Advantages

1. Simple structure: galvanized steel frame + plastic film cover + side ventilation.

2. Easy assembly: The precast steel pipe can be easily connected through some fasteners.

3. Large internal space, easy operation and maintenance.

The tunnel greenhouse cost is not high, you can get high yield with low input.

5. Long service life: The steel structure of greenhouse can be used for more than 10 years.

6. Multi-purpose: You can use a small tunnel greenhouse in your garden as a garden greenhouse, or you can have a large scale for your farm.

Covering Material

Clear PE film as the covering material; Thickness usually choose 0.15mm or 0.2mm;Cover the greenhouse with the film of 1 or 2 layers;Has the function of dust-proofand anti-dripping; To reduce water evaporation in soil;UV block treatment;Cost very few, easy to install and maintenance.

Name Thickness Guarantee period Types

Plastic Film

0.06mm 14 month

PVC;

PE;

EVA;

PO

0.08mm 18 month
0.10mm 2 years
0.12mm 3 years
0.15mm 4 years
0.20mm 5 years

150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame

150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame

Packing and shipping

Customers could choose air or railway or shipping as actual situation.
Packaging Details:
20ft container can load approximately 20 sets of greenhouses
Delivery Time:
Shipped in 10 days upon payment

  • Port: Shanghai/Guangzhou/Tianjin/Chongqing
  • Lead Time: Shipped in 10 days upon payment

150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame150mic PE Film Tunnel Plastic Greenhouse With Galvanized Steel Frame

Our services

1. Reliable design: a strong and creative design, research and development team to design the greenhouse according to the local climate and geographical conditions.

2. Greenhouse installation: engineers can be sent to your country for greenhouse installation.

3. Quality assurance: we have strict quality control and mature technology, our products have achieved

National and industry standards. All our exports will be strictly inspected before shipment.

4. One-to-one 24-hour online service: for any questions, please contact us.

5. After-sales service: if there is any quality problem during the warranty period, we will assume the responsibility and provide on-site service as needed.
