Specifications
Model Number :
YD280
Brand Name :
ALN
Payment Terms :
T/T,D/P,D/A,L/C
Delivery Time :
30-35work days
Description

Product Name: ALN-YD280 Dual-chamber Automatic Vertical Baling Machine

Equipment Purpose: Waste materials pass through the static eliminator pipeline and then enter the compression chamber of the baler. Static electricity is eliminated to prevent materials from sticking to the hopper inner wall. A photoelectric switch is fitted on the hopper above the compression chamber. When the material feeding height reaches the trigger level, the main oil cylinder drives the pressing plate to compress automatically and then retracts. The machine stays standby if the material height is insufficient. The compression-retraction cycle repeats until the preset bale length is reached. The threading rod automatically feeds the wire, the wire twister twists and cuts the iron wire, then the threading rod retracts. A complete bale is formed.
Full automatic operation via electric buttons and touch screen.

Equipment Dimension: 7100mm×3770mm×4300mm
Floor space of main unit

Finished Bale Size: 720×720×500-1000mm

Working Power Supply: 3P—380V—50Hz
Customizable for different countries and regions

Working Pressure: 16MPA

Compression Force: 60 tons

Feeding Hopper Size: 1000×640mm

Hydraulic Oil Type: L-HM 46 anti-wear hydraulic oil

Strapping Wires: 4 lines
Wire specification: ∮3.0mm

Bale Discharge Mode: Continuous bale output

Main Motor Power: 22KW

Machine Weight: 8000 kg

Production Capacity: 4-5 bales/h, 70-150kg per bale
Continuous output
