OS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single Mode
OS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single Mode
OS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single Mode
OS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single Mode
Specifications
Brand Name :
HFO
Model Number :
ST 0.9MM Patch Cord
Certification :
CE Rohs SGS ISO
Place of Origin :
China
MOQ :
MOQ : 10PCS
Price :
Price : Negotiable
Payment Terms :
Payment Terms:T/T, L/C,paypal,Western Union
Supply Ability :
Supply Ability :150000pcs/month
Delivery Time :
Delivery Time :3 to 5 days for sample orders, 7 to 15days for bulk order
Packaging Details :
Packaging Details : 1pc pp bag
Connector :
SC/UPC~ST/UPC
Color :
YELLOW/Other
Jacket Material :
PVC/other
Cable Configuration :
SM/SX
Fiber type :
OS2
jacket diameter :
0.9mm
Description

Fiber Optic Cable Patch Cord SC / UPC To ST / UPC OS2 Single-Mode Single-Core

Description:

The fiber optic patch cord is a length of optical cable with

connectors fixed on two ends to realize the optical path active connection. Pigtail is a length fiber

cable with only one connector fixed on one end. If both sides of the connector or its end-face are

different, we call it hybrid patch cord, according to the polished ceramic end-face, it divides PC, UPC and APC.

Fiber Optic Patch cords are the basic passive components of Optical Fiber Telecommunication System,are utilized to achieve accurate mounting for precision alignment of fiber optical components.We provide high quality optical fiber patch cords,100% tested quality guarantee before delivery,with ISO standards and RoHS compliant.

Specification:

Interface model:SC/UPC~ST/UPC Mode:Single-mode
Insertion loss:≤0.3dB Number of cores:Simplex
Return loss:≥55dB Ferrule type:Class A ceramic ferrule
Reliability:≤0.2dB Operating temperature:'-40℃to +85℃
Repeatability:≤0.1dB Fiber type:OS2
Tensile strength:45KG Outer sheath material:PVC(default),LSZH,OFNP
Tensile strength:≥200N Test wavelength:1310nm~1550nm
Mating times:≥1000times Cable outer length:0.9mm,2.0mm(default),3.0mm
Minimum bending radius:38mm Optical fiber specifications:9/125µm

OS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single ModeOS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single Mode

OS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single ModeOS2 Fiber Optic Patch Cord SC/UPC To ST/UPC Single Mode

Application

  • -Testing equipment;
    -FTTH+LAN;
    -Optical fiber CATV;
    -Optical communication system;
    -Telecommunication.

Features:

Our products contain splitter,MTP/MPO/MU/E2000/LC/SC/FC/ST fiber optic patch cord,high density panel,cassettes,plate,MTRJ, pigtail ,adapters, attenuator,PLC,FBT,fast connector ,Fiber Optic Splitter Box,Fiber Optic Cable Joint Box,Fiber Optic Splice Closure and customized product.

We sincerely look forward to building mutual development and achieving win-win cooperation.
