Full Gigabit POE SFP Fiber Switch With 24 POE Ports 1 SFP Port 1 Uplink Port
Full Gigabit POE SFP Fiber Switch With 24 POE Ports 1 SFP Port 1 Uplink Port
Specifications
Brand Name :
AEO
Certification :
CE, FCC
Place of Origin :
China
MOQ :
1 pair
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
10000 pairs/month
Delivery Time :
2-3 working days
Packaging Details :
package and carton
Voltage Range :
AC 100～240V
2 uplink Ethernet Port :
0-100M
POE power supply :
<320W
POE Agreement :
IEEE802.3 af/at standards
MTBF :
50000 hours
Switch Capacity :
52G
MAC Address :
8K
Working Temperature :
-10℃～55℃
Storage Temperature :
-40℃-85℃
Humidity(non-congeal) :
0~95%
Gigabit POE ports :
24
Gigabit SFP ports :
1
Gigabit Uplink port :
1
Jumbo frames :
10KB
Description

Full Gigabit POE SFP Fiber Switch 24 POE Ports + 1 SFP Port + 1 Uplink Port

Technical Parameters

Item Description
Model AEO-824GP-1G1SFP
Power Supply Power Supply Mode Mains on load
Voltage Range AC 100～240V
Power Consumption The device <15W, POE power supply <320W
Network Port Parameter Network Ports

1～24 Ports: 10/100/1000Mbps Ethernet port, adaptive control

UPLINK Ethernet port: 10/100/1000Mbps Ethernet port

Uplink SFP:1.25Gbps
Transmission Distance

1~24 Ethernet Port:0~100m

1 Ethernet Uplink Port:0~100m

1 SFP: According to different SFP
Transmission Media

1~24 Ethernet Port:Cat5e/6 standard UTP cable,

1 Ethernet Uplink Port:Cat5e/6 standard UTP cable

1 SFP: LC interface optical fiber
POE Agreement

IEEE 802.3af Power over Ethernet

IEEE 802.3at Power over Ethernet Plus
PoE Power Supply Mode End-span method
PoE Power Supply Wattage Each port≤30W,Whole device<400W
Network Switch Specification Network Standard

IEEE 802.3 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3ab Gigabit 1000BASE-T

IEEE 802.3z Gigabit SX/LX

IEEE 802.3x flow control and back pressure
Swap Mode Store-and- forward
Switch Capacity 52Gbps
MAC Address List 8K
Status Indicators Power Indicator Light One power light (green)
Optical Fiber Port Indicator One fiber link indication light ( green), Green light keeps on when the fiber port is well connected; Blinking when transceiver data
Uplink Port LED (Green): On, port is link on; Off, port is link down;
PoE Indicator 1~24 PoE indicator light
PoE Network Port LED 1~24 port ( green light on RJ45 jack) Keeps on when normally connected, Blinking when transceiver data
Protection Level Surge Immunity Level 3, executive standard:IEC61000-4-5
Electrostatic Protection 1a touch electric discharge: level 3 1a Air discharge: level 3 Executive standard:IEC61000-4-2
Operating Environment Working Temperature -10℃～55℃
Storage Temperature -40℃-85℃
Humidity(non-congeal) 5~95%
Mechanical Attributes Dimensions (L*W*H) 440mm×260mm×44mm
Color Black
Weight 4.5kg
Reliability Mean time between failures (MTBF) ＞50000h
Environment
Operating Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage Temperature: -20 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)


Product Overview
The AEO-824GP-1G1SFP is equipped with 24 10/100/1000BASE-T ports featuring 30-watt 802.3at Power over Ethernet Plus (PoE+) copper interfaces, 1 10/100/1000BASE-T ports RJ45 and 1 extra 1000BASE-X SFP slots with inner power system. With a total PoE power budget of up to 320 watts and non-blocking data switching performance, the AEO-824GP-1G1SFP fulfills the demand of sufficient PoE power for HD IP surveillance. It offers a rack-mountable, safe and reliable power solution for SMBs deploying Power over Ethernet networks.
The PoE in-line power following the IEEE 802.3at/af standard makes the AEO-824GP-1G1SFP able to deliver Gigabit speed data and up to 30 watts of power per port to 24 PoE compliant powered devices (PDs) with a combined power output budget of up to 320 watts. The AEO-824GP-1G1SFP provides more flexibility in power requirement for all kinds of PDs with affordable installation costs.

Product features

  • 24-port 10/100/1000BASE-T Gigabit Ethernet RJ45 copper with POE function
  • 1 1.25Gbps SFP interfaces
  • 1-port 10/100/1000BASE-T Gigabit Ethernet RJ45 copper
  • Complies with IEEE 802.3af/at Power over Ethernet end-span AEO
  • Up to 24 ports of IEEE 802.3af/802.3at devices powered
  • Supports PoE power up to 30.8 watts for each PoE port
  • Each port supports 52V DC power to PoE powered device
  • 320-watt PoE budget
  • Auto detects powered device
  • Circuit protection prevents power interference between ports
  • Remote power feeding up to 100m in standard mode
  • Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
  • Flow control for full duplex operation and back pressure for half duplex operation
  •  10 KB Jumbo frames support

Product Picture
Full Gigabit POE SFP Fiber Switch With 24 POE Ports 1 SFP Port 1 Uplink Port
Packaging & Shipping

● All of our package are international standard package
● We will deliver our products as soon as the order confirmed

Full Gigabit POE SFP Fiber Switch With 24 POE Ports 1 SFP Port 1 Uplink Port
