FTTH FC Fiber Optic Patch Cord Duplex Bend Insensitive Fiber Metal Housing
FTTH FC Fiber Optic Patch Cord Duplex Bend Insensitive Fiber Metal Housing
FTTH FC Fiber Optic Patch Cord Duplex Bend Insensitive Fiber Metal Housing
FTTH FC Fiber Optic Patch Cord Duplex Bend Insensitive Fiber Metal Housing
Specifications
Brand Name :
FOCABLE
Model Number :
FC/UPC Fiber Patch Cord
Certification :
RoHS Compliant, SGS Certificate, ISO Certificate
Place of Origin :
China
MOQ :
10PCS
Delivery Time :
3-5days
Packaging Details :
1PCS/PE Bag
Fiber Type :
SM, OM1, OM2, OM3, OM4
Cable Material :
PVC, LSZH, OFNP, OFNR, Hytrel
Cable Diameter :
0.9mm, 1.6mm, 1.8mm, 2.0mm, 2.4mm, 3.0mm
Connector :
SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST, E2000, MU, MPO, MTRJ
Cores :
Simplex, Duplex, 4cores, 6cores, 8cores, 12cores, 24cores, 48cores
Length :
1M, 2M, 3M, 5M or as per customer request
Description

FTTH FC Fiber Optic Patch Cord Duplex Bend Insensitive Fiber Metal Housing
Connector type, FC, SC, LC, ST, MU, MTRJ, E2000, MPO
If multimode, OM1 62.5/125um, OM2 50/125um, OM3, OM4 fiber can be chosen.
If single mode, G.652D, G.655, G.657 fiber can be chosen.
For cores, there are simplex, duplex, 4core, 6core, 8core, 12core, 24core
For cable jacket, PVC, LSZH, PU, OFNP, OFNR
For cable color, SM yellow, MM orange, other colors can also be available upon request
Single mode fiber optic patch cords can be used to cross connect patch panels. As connector styles evolved hybrid cables become more popular.

FC optical fiber cords are widely used in fiber optic systems. FC standard fiber optic connectors are used for telecommunications, CATV, LAN, MAN, WAN, Test & Measurement, Industry, Medical and Sensors. FC fiber optic connectors comply with IEC 61754-13 & CECC 86 115-801 standards. They are well known for general, average applications. We supply single mode and multimode version FC fiber jumper cables and FC fiber optic components.

Features
Low insertion loss, high return loss
High dense connection, easy for operation
High credibility and stability
Good in repeatability and exchangeability

Applications
Local Area Networks(LANS)
Data Processing Networks
Premise Installations
Active Device Termination
FTTX
Fiber Optic Telecommunication
Testing Instruments

Specifications

Connector

FC, SC, ST, LC

UPC

APC

Insertion Loss

≤0.3dB

Return Loss

≥50dB

≥60dB

Cable Outer Diameter(mm)

￠0.9, ￠2.0, ￠3.0

Durability

≤0.3dB(1000 matings)

Interchangeability

≤0.2dB

Operating Temperature

-40℃～+80℃


FTTH FC Fiber Optic Patch Cord Duplex Bend Insensitive Fiber Metal Housing

Fiber Optic Patch Cord, Optical Fiber Patch Cord, Fiber Optic Assemblies, Fiber Jumpers
