Specifications
Place of Origin :
Shenzhen , China
Brand Name :
CY COM
Certification :
ISO9001:2015 , RoHS
MOQ :
20
Packaging Details :
Plastic Box
Delivery Time :
in 3-5 days
Payment Terms :
L/C,T/T,Western Union payments for offline orders.
Supply Ability :
4.5 MIllion PCS / Month
Material :
Plastic
color :
Cream, Blue
certificate :
ROHS, ISO
Insertion Loss (IL) :
0.2
Description

Low Insertion Loss MU Fiber Optic Adapter for Computer Networks

MU fiber adapter is a mechanical device designed to align fiber-optic connectors. It contains the interconnect sleeve, that holds the two ferrules together.
MU adapters are approximately half the size of an SC coupler and utilize zirconia sleeves for precision alignment.

Features:
Low insertion loss, high return loss
Good compatibility
High precision of mechanical dimensions
High reliability & stability
Ceramic or Bronze Sleeve
PC, APC, UPC optional
Simplex / Duplex

Specification:
Insertion loss: < 0.2dB
Repeatability: < 0.2dB
Exchangeability:< 0.2dB
Retention force: 200-600G
Durability Time: �1000
Temperature range: -40 - 80 degree Celsius

Sleeve Material: Ceramic or beryllium bronze;
Housing Material: Synthetic resin or alloy, with high precisemechanical dimensions, good compatibility;
Working Wavelength: 1200~1600nm
Working Condition: -40°C to +75°C;
Durability: less than 500 times repeated insert and pull out , insertion loss change≤0.20dB;
Repeatability: No more than 0.2dB ;
The adapters comply with the standard of NTT/Telcordia/IEC/TIA/EIA.
Mode: SM/APC Green SM/PC Blue MM/PC Beige MM/PC Light Green

Application:

1.Telecommunication
2.Computer networks
3.CATV networks
4.Active device termination
5.Instrumentation
Cream color Low Insertion Loss MU Fiber Optic Adapter for Computer NetworksCream color Low Insertion Loss MU Fiber Optic Adapter for Computer NetworksCream color Low Insertion Loss MU Fiber Optic Adapter for Computer NetworksCream color Low Insertion Loss MU Fiber Optic Adapter for Computer NetworksCream color Low Insertion Loss MU Fiber Optic Adapter for Computer NetworksCream color Low Insertion Loss MU Fiber Optic Adapter for Computer Networks
