Specifications
Brand Name :
OPTFOCUS
Model Number :
OFS-GSF2DT16
Place of Origin :
Shenzhen China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
5000 piece per one week
Delivery Time :
5-7working days
Packaging Details :
300mm×230 mm× 95mm
Product Name :
16-port 10/100Mbps + 2-port 1000Mbps SFP
Product Model :
OFS-GSF2DT16
Power Supply input :
AC100 ～ 250V
Input voltage range :
DC5~15V
Max power :
8W
Environment temperature :
0 ～ +55℃
Humidity :
5% ～ 90%
Product size :
207mm× 140mm× 45mm
Description

16-port 10/100Mbps + 2-port 1000Mbps SFP Fiber Switch

Product Description

Technical Specifications

Product Name 16-port 10/100Mbps + 2-port 1000Mbps SFP Fiber
Product Model OFS-GSF2DT16
Network Protocols IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;IEEE802.3u;100Base-TX/FX;IEEE802.3ab 100Base-T; IEEE802.3z 1000Base-X; IEEE802.3x;
Network Media 10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter)
Fiber Media Multi-mode: 2KM
Single-mode: 20/40/60/80/100KM
Performance Specification Bandwidth: 5Gbps
Packet Forwarding Rate:148800pps/port
MAC Address Table:4K
Forwarding Mode Store-and-Forward
LED Indicators Power: PWR;FX Link/Act;TP FDX(1-16);
TP Link/Act(1-16)
Input voltage range DC5~15V
Power Supply external PS Input: AC100 ～ 250V, Output:DC5V 2A；
Max power 8W
Environment temperature 0 ～ +55℃
Storage temperature -20 ～ +70℃
Humidity 5% ～ 90%
Installation DIN-Rail or Wall mounts,Optional,Default device is not
Packing List 1× Switch
1×User Manual/Certificate of quality/Warranty card
1×power adapter
MTBF 100,000 hours
Weight & Size Product Weight: 0.5 KG
Packing weight: 1.1 KG
Product size (L×W×H): 207mm× 140mm× 45mm
Packing size(L×W×H): 300mm×230 mm× 95mm
Warranty 1-years

Feature:

  • 16 Port 10/100Mbps with Auto Uplink™ , 2 port 1000Mbps SFP Slot

  • Automatic MAC address learning and aging

  • 10/100Mbps Auto-negotiation , auto-MDI-MDI-X

  • LED indicators for monitoring power/link/activity

  • Support 10/100Mbps-Full/Half-duplex

  • Supports Wall-mount and DIN-Rail installation ,Optional.

  • Supports Broadcast Storm Control

  • Excellent heat elimination without cooling fan.

  • Apply to Urban Intelligent Traffic Monitoring System (ITS), Safe City.

  • Harsh environment or higher requirement

  • -10℃-55℃operating temperature range.

  • Redundant dual DC power inputs

Product Exhibition

Most popular & high quality 16* 10/100Base-T RJ45,2* 1000M fiber SFP ports, without SFP module

SFP Ethernet Network Switch 8W Max Power Wall Mounts Installation 207mm × 140mm × 45mm

SFP Ethernet Network Switch 8W Max Power Wall Mounts Installation 207mm × 140mm × 45mm

SFP Ethernet Network Switch 8W Max Power Wall Mounts Installation 207mm × 140mm × 45mm

SFP Ethernet Network Switch 8W Max Power Wall Mounts Installation 207mm × 140mm × 45mm

Application

SFP Ethernet Network Switch 8W Max Power Wall Mounts Installation 207mm × 140mm × 45mm
