High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
High Reliable Fiber Optic Switch 2 Port 10 / 100 / 1000M With Broadcast Storm Control
Specifications
Brand Name :
OPTFOCUS
Model Number :
OFS-GSF2T2
Place of Origin :
Shenzhen China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
5000 piece per one week
Delivery Time :
5-7working days
Packaging Details :
233mm×152 mm× 55mm
Product Name :
2-port 10/100/1000Mbps + 2-port 1000Mbps SFP Fiber
Product Model :
OFS-GSF2T2
Power Supply input :
AC100 ～ 250V
Forwarding Mode :
Store-and-Forward
Max power :
5W
Environment temperature :
0 ～ +55℃
Humidity :
5% ～ 90%
Product size :
140mm× 93mm× 28mm
Description

High reliable Fiber optic switch 2 port 10 / 100 / 1000M RJ45 to 2-port 1000 SFP port

Product Description

Technical Specifications

Technical items Description
Product Name 2-port 10/100/1000Mbps + 2-port 1000Mbps SFP Fiber
Product Model OFS-GSF2T2
Network Protocols IEEE802.3 10BASE-T; IEEE802.3i 100Base-T;IEEE802.3u;1000Base-TX/FX;IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x;
Network Media 10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter)
1000BASE-TX: Cat6 or later UTP(≤100 meter)
Fiber Media Multi-mode:550M- 2KM
Single-mode: 20/40/60/80/100KM
Performance Specification Bandwidth: 8Gbps
Packet Forwarding Rate:1488000pps/port
MAC Address Table:1K
Forwarding Mode Store-and-Forward
LED Indicators Power: PWR;FX Link/Act;TP 1000(1-2);
TP Link/Act(1-2)
Power Supply Adapter:
Input: AC100 ~ 250V, Output:DC5V 2A.
Max power 5W
Environment temperature 0 ～ +55℃
Storage temperature -20 ～ +70℃
Humidity 5% ～ 90%
Installation DIN-Rail or Wall mounts,Optional,Default device is not
Packing List 1× Switch
1×User Manual/Certificate of quality/Warranty card
1×power adapter
MTBF 100,000 hours
Weight & Size Product Weight: 0.5 KG
Packing weight: 1.1 KG
Product size (L×W×H): 140mm× 93mm× 28mm
Packing size(L×W×H): 233mm×152 mm× 55mm
Warranty 1-years

Feature:

  • 2 Port 10/100/1000Mbps with Auto Uplink™ , 2 port 1000Mbps SFP Slot
  • Automatic MAC address learning and aging

  • 10/100/1000Mbps Auto-negotiation , auto-MDI-MDI-X

  • LED indicators for monitoring power/link/activity

  • Support 10/100/1000Mbps-Full/Half-duplex

  • Supports Wall-mount and DIN-Rail installation ,Optional.

  • Supports Broadcast Storm Control

  • Excellent heat elimination without cooling fan.

  • Apply to Urban Intelligent Traffic Monitoring System (ITS), Safe City.

  • Harsh environment or higher requirement

  • -10℃-55℃operating temperature range.
