Dual Core MTRJ To ST Fiber Optic Jumper Cables With Multimode Orange Optical Cable
Dual Core MTRJ To ST Fiber Optic Jumper Cables With Multimode Orange Optical Cable
Dual Core MTRJ To ST Fiber Optic Jumper Cables With Multimode Orange Optical Cable
Dual Core MTRJ To ST Fiber Optic Jumper Cables With Multimode Orange Optical Cable
Specifications
Brand Name :
Fiberall
Model Number :
FAPC-TPJPM2
Certification :
RoHS, UL, ISO9001
Place of Origin :
China
MOQ :
50pcs
Price :
Upon request
Payment Terms :
L/C,T/T,Western Union, MoneyGram,PayPal
Delivery Time :
3-5 days
Packaging Details :
Plastic bag/Inner Carton/Outer Carton
Product Name :
Fiber Optic Patch Cord
Fiber Type :
OM1, OM2, OM3, OM4 for options
Connector 1 :
ST
Connector 2 :
MT-RJ
Sheath Color :
Orange
Cable dimension :
2.0 duplex
OEM Service :
Available
RoHS compliant :
Yes
Description

FAPC-TPJPM2 , Dual Core MTRJ To ST Fiber Optic Jumper With Multimode Orange Optical Cable

Optical fiber jumper can provide a quick and easy connection in the field. The pre-terminated connector allows the installer to terminate and make connection in minutes at equipment and fiber patch panels. Fiberall fiber optic jumper is with excellent end face polishing before they left the factory and operator just need to clear the interface on the equipment or patch pane; then insert the connector into it. All the key steps have been done in the factory to ensure every connection is precision.

MT-RJ fiber connector is started from the MT connector developed by NTT , external parts of the connector are precision plastics, including push and pull plug (clamping mechanism). With same latch mechanism like RJ-45 type LAN electrical connector , to align optical fiber via the guide pin installed in both sides of the small casing so that it can be connected accurately with optical transceiver. The end face is with dual core (0.75mm interval), so transmitting and receiving can be integrated into one unit. It is mainly used for next generation high density optical fiber connector of data transmission and it is suitable for indoor applications in telecommunications and data network systems.

Product Parameters

Part number FAPC-TPJPM2
Cable Spec Fiber Optic Jumper ST/PC- MTRJ MM Duplex 2.0mm Orange Jacket
Cable size 1.8×3.7(mm)
Fiber Spec OM1 62.5/125um or OM2 50/125um
Insert Loss ≤0.3dB(0.25dB typical)
Durability <0.20 dB typical change, 1000 mating
Operating Temperature From -40 to + 80°C
Ferrule Hole Spec 125μm, Concentricity: 1≤3μm
127μm, Concentricity: 1≤3μm
128μm, Concentricity: 1≤3μm

Application


Testing equipment
Optical fiber CATV
Optical communication system

Data center

Optical fiber distribution

Local Area Networks (LANs) and Wide Area Networks (WANs)
FTTx, FTTH, FTTB, FTTP etc
Transmission Mode (ATM)
Fiber Optic Backbone
Military Instrumentation
