LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua
LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-001
Certification :
CE, FDA, SGS, RoHs, ISO9001:2008
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25000PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Fiber Count :
12 Cores
Cable OD :
3.0mm
Connector Type :
MTP, USConec
Length :
10feet
Glass Fiber :
Corning ClearCurve®
Wavelength :
850nm/1300nm
Description

10 FT Fiber Cable LSZH MTP OFNR 12 Cores Multimode OM3 Aqua

12 Cores Fiber Optic Multimode MTP to MTP Female End Aqua OM3 Trunk Cable

Products Description

Hangalaxy's MTP trunk cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles. With US Conec MTP connectors and Corning Clearcurve fiber, it is optimized for 10/40/100G high-density data center applications. Please note: The US Conec MTP connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors. And today we has 12F and 24F MTP Cable for producing and our quality to meet your standard requested.

Keyed Characteristics


• NTT Compatible;
• Low loss interconnect;
• Push-pull mating of MTP for quick connections;
• 100% tested;
• Compliance with the 40 and 100Gbps protocols.
• Consistent and repeatable performance.

Cable Performance

Fiber Type (ISO/IEC 11801) 50/125um, OM3, Aqua

Attenuation Coefficient (dB/km)

 ≤ 3.5 Max (850nm)
≤ 1.5 Max (1300nm)
≤ 2.7 Typ (850nm)
≤ 0.9 typ (1300nm)

Standards Compliance

 TIA/EIA-568-C.3 and ISO/IEC 11801
Color Options MM Elite (Aqua)
Minimum Bandwidth: Laser Effective Modal Bandwidth[Mhz-km] ≥2000 (850nm)
Jacket Material Riser - OFNR
LSZH - Low Smoke Zero Halogen
Plenum - OFNP
Plenum - OFNP

Connector Performance - MTP®

Type and Color Code Connectors Insertion Loss (IL) Optical Return Loss (RL) Operating Temperature
Multimode MTP® Standard Connector 0.35 dB Typical (All Fibers)
0.75 dB Maximum (Single Fiber)1,3		 > 20 dB (0°Flat Polished)2,3 -40℃ to 75℃
1 IL test according to IEC 61300-3-4;
2 RL test according to IEC 61300-3-6;
3 Tested with proposed encircled flux launch condition on 50μm fiber & 850nm per IEC 61280-4-1.

Application

  • Telecommunication networks
  • Data centers
  • Supports SFP, QSFP, CFP applications
  • 40G to 10G transition
  • CATV;
  • Active device termination;
  • Telecommunication networks;
  • Metro;
  • Local Area Networks;
  • Data processing networks
  • Test equipment;
  • Premise installation;
  • Wide Area Networks

Testing Equipment

LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua

Products Picture

LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua

LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua

LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua

Eco-Friendly Packaging & Labeling


This easy to take and well-protected fiber optical cable package has been labeled and marked by Hangalaxy as default. Customized label or package solution are available on request.

LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua
