4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m
4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m
4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m
4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m
4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m
4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m
Specifications
Brand Name :
Hangalaxy
Model Number :
HN76362
Certification :
CE, FDA, SGS, RoHs, ISO9001:2008
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1PCS Each Individual Quality PE Bag
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Cable OD :
4.1mm
Fiber Count :
4
Port :
HDMI
Data Rate :
48 Gigabytes
Color :
Black
Length :
100meters
Description

4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable with USB Power Supply

Description


This kind of Active Optical Cable (AOC) from Hangalaxy which is a cabling technology that accepts same electrical inputs as a traditional copper cable, but uses optical fiber between the connectors to extend HDMI signals with zero loss or latency. The Hangalaxy AOC 150 meter (623 feet) HDMI 2.0 cables with Ethernet are designed with fiber optical technology to deliver UltraHD with a super bandwidth of 18Gbps. These latest specs from HDMI deliver uncompressed 4K resolutions with 32 audio channels for a multi- dimensional immersive audio and up to 1536 kHz sample frequency to attain highest audio fidelity.

Keyed Characteristic


Hangalaxy HDMI AOC- Active optical cable which is 150m;
Premium video quality up to 4096x2160@60Hz;
Bandwidth up to 18Gbps;
Color Sub-sampling of 4:4:4 with Deep Color & HDR;
EMI/RF free for clear signal transmission;
Plug and Play;
HDMI connector designed by fully shielded, prevent electromagnetic and radio frequency signal interference;
Low power consumption;
Support color depths to 48 bits;

Practical Advantages


High bandwidth and long-distance signal transmission;
Highly integrated, plug and play less interfaces connected make stable transmission links;
EMI/RF free for clear signal transmission;
Easy read all EDID data by optical transmitted technology;
Using ClearCurve® fiber;
2 HDMI connector designed by photoelectric conversion chip drive by DC5V from main equipment.

Technical Parameter

Cable Length Max 150 meters
Cable OD 4.1mm
Connector Type HDMI Standard Type A (Male) - HDMI Standard Type A (Male)
Cable Type Hybrid Optical Cable with OM3 Fiber and Copper Wire
HDMI Version 2.0
Supports Resolutions Supports resolutions up to: 4K@60Hz, 4:4:4
HDTV 4096×2160@60Hz
Bandwidth 18 Gbps
Regulatory Compliance CE, FCC, RoHs compliant

4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m

4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m

4.1mm 48 Gigabytes HDMI2.1 AOC Active Optical Cable 150m

Application

(1) Home Theatre;
(2) HD Video Conference System;
(3) Large Outdoor Screen Display;
(4) Large Medical Imaging System;
(5) Radio and Television System;
(6) HD Surveillance System.
