Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Specifications
Brand Name :
Hanglaxy
Model Number :
HGYN-0147
Certification :
SGS, CE, RohS, UL, FDA
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram, L/C
Supply Ability :
5055PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Material :
Metal
Color :
White
Fiber Count :
24
Connector Type :
LC UPC
Fiber Mode :
Multimode, OM3
Dimension :
1U, 19inch
Insertion Loss :
0.5dB
Return Loss :
35dB
Description

1U 12F Duplex LC UPC Multimode OM3 Fiber Optic Termination Metal Box

Hangalaxy this kind of rack mounted fiber optic patch panel has been designed to facilitate internal fiber management. It is made of 16 gauge steel sheet by electrostatic plastic spraying and providing good protection, connection, termination and management for fibers. The standard 19 inch drawing out design allows fiber installation and maintenance operation from the front. The pigtails color code are according to TIA/EIA 598A , pigtail and adapter are Telcodia, TIA/IEC and JIS compliant. Various pigtail and adapter including ST, FC, SC, LC ect for optional.

Physical Features

Capacity of 24 optical fiber couplers

Front and back protection

Fittings and accessories are mounted

Fiber organizer and fiber identification are included

Weight: 4.8kg at 48x35x4.5cm

Application

Telecommunications
Local Area Network
FTTH deployments
Data Processing Networks

Usage Environment

Environment temperature: -40°~+80°
Relative humidity: ≤85% (30°)
Insulated Resistance:≥2×10MΩ/500V(DC)
Atmosphere pressure: 70~106KPa

Specification

Part Number HGYN-0147
Fiber Capacity 24 fibers
Material Metal
Color White
Connector Type LC UPC
Fiber Mode Multimode, OM3
Dimension 48x35x4.5cm
Weight 1.56kg
Durability 1000times
Relative Humidity ≤85% (30°C)

Usage Environment

Environment Temperature

-40°C~+80°C
Relative Humidity ≤85% (30°C)
Insulated Resistance ≥2×10MΩ/500V(DC)

Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3

Product Photo and Accessories

Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3

Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
