E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
Specifications
Model Number :
E2000/PC-20, E2000/PC-20
Place of Origin :
Guangdong, China
Brand Name :
Chuanglixun
MOQ :
1
Price :
$398-412
Material :
Stainless Steel S136
Dimensions :
174mmx174mmx26mm
Weight :
1.2kg
No. of Fiber :
24
Ferrule Holder size :
2.5mm
Connector Type :
FC PC
End-face :
PC
Ferrule Diameter :
2.5mm
Capacity :
24 positions
Insertion Loss :
≤0.20dB
Return Loss :
≥55dB (PC)
Radius of Curvature :
5-25mm
Apex Offset :
0-50μm
Fiber Height :
-100~+50μm
Angle :
8.00+/-0.50°
Description
E 2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use
Product Overview
This high-stability fiber polishing fixture/jig delivers exceptional surface quality for E2000/PC-20 connectors. Manufactured from premium hardened steel S2316 with heat treatment, it ensures long service life and reliable performance in FTTH applications.
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
Key Features
  • Specifically designed for E2000/PC-20 connectors
  • Easy jig changing with simple, flexible operation
  • High efficiency: polishes up to 20 connectors per cycle
  • First-pass yield for end face quality reaches 98%-100%
  • IPC structure with independent compression for each connector
  • Pass rate with interference ≥98% (typically 100% per IEC standards)
  • PC return loss ≥55dB, insertion loss ≤0.20dB (typical)
  • Replaceable accessories extend service life significantly
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
Technical Specifications
Model FC-PC-24 FC-PC-32 FC-PC-36
Brand CLX CLX CLX
Connector Type FC PC FC PC FC PC
End-face PC PC PC
Ferrule Diameter 2.5mm 2.5mm 2.5mm
Capacity 24 positions 32 positions 36 positions
Insertion Loss ≤0.20dB ≤0.20dB ≤0.20dB
Return Loss ≥55dB (PC) ≥55dB (PC) ≥55dB (PC)
Application Polishing assembled FC PC connectors
Material Stainless Steel
Dimension (L*W*H) 174*174*26 mm
Net Weight / Gross Weight 1.5 kgs / 2.0 kgs
Suitable Machines CLX-02E polishing machine, Seikoh Giken SFP-550 polishing machine, and similar machines
Polishing Performance Results
Polished Connector Ferrule Faces:
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
High-quality end-face polishing with no white spots, no scratches, and clearly visible fiber edges.
Insertion Loss & Return Loss Test Results:
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
Connector Type SM/UPC SM/APC MM/UPC
Insertion Loss ≤0.20dB ≤0.20dB ≤0.50dB
Return Loss ≥55dB ≥60dB ≥30dB
Geometry Test Results:
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
Parameter UPC Criterion APC Criterion
Radius of Curvature 5-25mm 5-12mm
Apex Offset 0-50μm 0-50μm
Fiber Height -100~+50μm -100~+50μm
Angle n/a 8.00+/-0.50°
Manufacturer Profile
E2000/APC20 Port Optical Fiber Polishing Fixture for FTTH Use with Stainless Steel S136 Construction
Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd., established in 2010, is an optical communications equipment company integrating research and development, production, after-sales service and technical services. We provide high-quality products, comprehensive after-sales service, and free technical support for optical fiber connector production challenges.
