Specifications
Model Number :
CLX-JX240, CLX-JX240
Place of Origin :
Guangdong, China
Brand Name :
CLX, CLX
MOQ :
1
Price :
$400-414
Machine Size :
92.5(L)x 46(D) x 31.5(H) mm
Net Weight :
260g
Electric Power :
126W
Relative Humidity :
15%~85%
Temperature Setting :
80℃ /100℃/ 120℃ /130℃
Power Supply :
Adapter to convert DC12V
Stripping Method :
Linear axis guidance + heat seeding
Stripping Length :
Up to 35mm
Fiber Core Capacity :
2-12 core ribbon fiber
Insertion Loss SM/UPC :
≤0.20dB
Insertion Loss MM/UPC :
≤0.50dB
Return Loss SM :
≥55dB
Return Loss MM :
≥30dB
Radius of Curvature :
5-25mm (UPC), 5-12mm (APC)
Apex Offset :
0-50μm
Description
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Fiber Optic Equipment Fibre Optic Patchcord FC SC ST LC Connector Grinder For Fiber Optic Jumper Production Line
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Product Description
Auto optical fiber stripper is specially designed for end-span strip of single and ribbon fiber automatically with length operation to 35mm. It maintains high tensile strength of optic fiber when stripping, and free from crack on the fiber surface. Auto Stripper generally used for laboratory and factory which study and produce fiber optic product.

Product Features

*Suitable for stripping 2-12 core ribbon fiber, compact and light.

*Using linear bearing guidance and hot stripping methods to ensure no damage to the optical fiber.

*Easy to strip the coating layer, stripping efficiency and high quality.

*Possess the function of stripping the whole strip and window stripping.

*The blade is durable and easy to replace.

*Compared with the previous model, the stripping force can be reduced by 80%.

Get a free Quotation via Us >>>GO
Polishing Effect
1. Fiber end face inspection results:
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force

High-quality end-face polishing, no white spots, no scratches, the fiber edge is clearly visible

2. ILRL Test Result:
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Connector Type
SM/UPC
SM/APC
MM/UPC
Insertion Loss
≤0.20dB
≤0.20dB
≤0.50dB
Return loss
≥55dB
≥55dB
≥30dB

3. Geometry Test Result:
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
NO.
Parameters
UPC Criterion
APC Criterion
1.
Radius of Curvature
5-25mm
5-12mm
2.
Apex Offset
0-50μm
0-50μm
3.
Fiber Height
-100~+50μm
-100~+50μm
4.
Angle
n/a
8.00+/-0.50°
Get a free Quotation via Us >>>GO
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd.
Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd. was established in 2010. Is an optical communications equipment company integrating research and development, production, after-sales service and technical services. We not only sell high-quality products and provide good after-sales service,but also provide free technical support to our customers. For the technical problems encountered in the production of optical fiber connectors, there are good solutions.
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Certifications
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
About shipping：We usually use DHL, FEDEX, UPS, EMS, TNT or Sea, these are the world's largest shipping companies, you can provide us with your courier account, we will help you choose the cheapest and the cheapest according to the quantity
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
Thermal Jacket Auto Fiber Stripper for Single and Ribbon Fiber with 80% Reduced Stripping Force
1.Are you a factory or a trader？
......we are factory.
2.What is your MOQ?
......MOQ 1 piece.
3.Do you provide sample services？
......Yes, we will provide samples.
4.How will you ship to me?
....... We will spend 4 to 6 days via DHL or FedEx. Properly extended based on order quantity .
5.How do we pay?
......Book in advance or multiple payment methods such as T / T and T / L.
6.How long is your product warranty?
......The warranty period is 1 year (the warranty period will provide free repairs, except for consumables). After the warranty period, accessories will continue to be provided and will be charged at cost.
7.Do you provide customized services？
......Yes, we provide customized services, According to customer requirements and description.
