24V IMU Inertial Measurement Unit Customized Fiber Optic IMU 135×119×99 mm JT-I MU
24V IMU Inertial Measurement Unit Customized Fiber Optic IMU 135×119×99 mm JT-I MU
Specifications
Place of Origin :
china
MOQ :
negotiable
Price :
negotiable
Delivery Time :
According to customer's requirement
Payment Terms :
Negotiable
Supply Ability :
Strong production capacity
Brand Name :
JTZG
Product Name :
IMU Inertial Measurement Unit
Technology :
Fiber Optic Gyroscope
Grade :
Industrial
Applications :
Aerospace, Defense, Navigation, Robotics
Customized Support :
OEM, ODM
Dimensions :
135×119×99 mm
Description

JT-I MU 1 35 Inertial Measurement System

The JT-IMU135 fiber optic inertial measurement unit uses a three-axis fiber optic gyroscope (FOG) to sense the angular motion of the carrier and output a digital signal proportional to the angular velocity of the carrier; three orthogonally configured quartz flexible accelerometers sense the linear acceleration of the carrier, providing the best cost-effective solution. Compared with other similar gyro technologies, fiber optic gyroscopes have significant advantages in life and stability.

Gyro measurement channel

parameter

Range ( °/s )

±300

Bias stability ( °/ h,100s, 1σ )

0.01

0.02

Zero bias repeatability ( °/ h)

0.01

0.02

Random walk ( /√h)

0.001

0.002

Startup time (s)

≤5

Magnetic shielding

The optical fiber ring of key sensitive devices has magnetic shielding

Scale factor nonlinearity (ppm)

≤50

Scale factor asymmetry (ppm)

≤50

Scale factor repeatability (ppm)

≤50

Acceleration measurement channel

parameter

Range (g)

±10 / ±20 / ± 40 optional

Bias ( μg )

≤ 50

Bias stability ( μg )

≤20(4h)

≤40 (3 months)

Scale factor (^/s)

5 0000± 5 000

Scale factor symmetry (ppm)

≤20

Scale factor stability (ppm)

≤ 5 0

Startup time

10s normal output

Mechanical and electrical interface

Communication interface

J30J-15ZKP , J30J-25ZKP

Communication

RS422 , RS232 , customizable

Operating voltage

+24V

Dimensions

1 35 × 1 19 × 99 mm

weight

≤ 2.5 kg​

Operating temperature

-20 ℃ ~ + 60 ℃

-40 ℃ ~+60 ℃

Storage temperature

-5 5 ℃ ~+8 5 ℃

24V IMU Inertial Measurement Unit Customized Fiber Optic IMU 135×119×99 mm JT-I MU

JT-IMU135 installation dimensions
