GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct
GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct
Specifications
Brand Name :
JUNPU
Model Number :
Outdoor Figure 8 Core Fiber Optical Cable
Certification :
ROHS, CE, CCC
Place of Origin :
China
Payment Terms :
T/T
Supply Ability :
30000 Kilometer/Kilometers per Week
Delivery Time :
1 ~ 10 Working days based on the quantity
Packaging Details :
wooden reel of Junpu GYTC8A Figure 8 Fiber Optical Cable Self-Supporting Optic Fiber Cable Duct
Application :
Telecommunication,outdoor aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise
Fiber type :
G652D,OM3,G657A2,50/125,62.5/125
Number of conductors :
≥ 10
Fiber count :
1-144 core
Jacket material :
PE,LSZH
Product Name :
Outdoor Figure 8 Core Fiber Optical Cable
Loose Tube Material :
PBT
Package :
2km/roll
Strength member :
Steel Wire
Description

GYTC8A Outdoor Figure 8 Core Fiber Optical Cable Self-Supporting Optic Fiber Cable Duct


Decsripttion

  • The optical fiber unit is positioned the center.Two prallel Fiber Reinforced (FRP)are placed at the two sides.Then the cable is completed with a black or color LSZH sheath.APL moisture barrier,finally extrusion PE sheathed cable.

GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct

Application

  • Mainly adopted to the conditions that with the laying method of aerial and the span under 100m, speeding up the installation, and saving the messenger wire and optic cable pothhook.

GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct

Optical Characteristics

Strength Member

Dimension

2.4(0.8*7)mm

Material

Steel Wire

Outer Sheath

Dimension

(9.2±0.3)mm×(16.5±0.5)mm(4-24F)

(9.6±0.3)mm×(16.9±0.5)mm(36F)

(10.1±0.5)mm×(17.4±0.7)mm(48F/60F)

(10.7±0.5)mm×(18.0±0.7)mm(72F)

(12.2±0.5)mm×(19.5±0.7)mm(96F)

(14.8±0.5)mm×(22.1±0.7)mm(144F)

Material

PE

Color

Black

Fiber Attenuation Coefficient in Cable

dB/km(1310nm)

≤0.36dB/km

dB/km(1550nm)

≤0.22dB/km
GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct
Package
GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct
GYTC8A Figure 8 Core Outdoor Fiber Optic Cable Self - Supporting Duct
We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
