SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper
Specifications
Brand Name :
JUNPU
Model Number :
Optical Patch Cord
Certification :
ROHS CE CCC
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, Credit Card Via Alibaba
Delivery Time :
1 ~ 10 Working days based on quantity
Packaging Details :
Standard Strong Carton Box
Product Name :
Simplex Fiber SC Optical Patch Cord FTTH
Connector :
SC, LC, FC
Fiber Mode :
Singlemode
Length :
1m, 2m, 3m, 5m As Your Customeried
Jacket :
PVC/LSZH
Description

Junpu SC Type Fiber Optic Patch Cables, Single Mode, LSZH, 1M Fiber Optic Jumper

Quick details:

  • Fiber Optic Patch Cable is also known as fiber optic jumper or fiber optic patch cord. Fiber Optic Patch Cable is essential for optical networks. They have the same or different connectors installed on the end of the fiber optic cable. Fiber optic patch cables are used in two major application areas: computer workstations to outlet and patch panels or optical cross-connect distribution centers. The Fiber Optic Patch Cord series comes with a comprehensive collection of lengths and connectors to fulfill your demand for deployment.

Features:

  • Screw-thread coupling mechanism
  • Ceramic ferrules
  • Low insertion loss, high return loss
  • Good in repeatability and exchangeability
  • 100% Insertion, Return Loss, End Face, and Interference inspection
  • Excellent mechanical endurance
  • High credibility and stability
  • Complying with Telcordia , GR-326-Core, IEC, and RoHS Standard

Applications:

  • Optical access network
  • Data processing networks
  • Premise installations
  • Local Area Networks(LANs)
  • Wide Area Networks(WANs)

Specification:

Pigtail Connector PC (SM) UPC (SM) APC (SM) MM
Return Loss (dB) ≥45 ≥50 ≥60 ≥35
Insertion Loss (dB) ≤0.2 (max≤0.3)
Repeatability (dB) ≤0.1
Durability(1/Matings) ≥500
Operation Temperature (°C) -25~+70
Tensile Strength (N) ≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9
Fiber 9/125um, 50/125um,62.5/125um,ect
diameter 0.9mm 2.0mm, 3.0mm etc
Cable material PVC, LSZH
Cores Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc
G.652 G.655 50/125μm 62.5/125μm
Attenuation @850nm ≤3.0 dB/km ≤3.0 dB/km
(+20℃) @1300nm ≤1.0 dB/km ≤1.0 dB/km
@1310nm ≤0.36 dB/km ≤0.40 dB/km
@1550nm ≤0.22 dB/km ≤0.23dB/km

Bandwidth

(Class A)

 @850nm ≥500 MHz·km ≥200 MHz·km
@1300nm ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelengthλcc 1260nm ≤1480nm

Ordering Information

Boot

(cable size)

 Boot Color Fiber Type Cable number Ferrule Length

0.9mm

2.0mm

3.0mm

Black

Beige

Blue

Gray

White

Yellow

9/125um SM

50/125um MM

62.5/125um MM

OM3

OM4

Simplex

Duplex

Multi-fiber

UPC

APC

 Customized

SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumperSC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumperSC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper

Other Patch Cord Series:

SC Type Fiber Optic Patch Cables, single mode, LSZH, 1M fiber optic jumper

We sincerely invite you to send us an inquiry for further details.

Junpu Cares About Every Single Details Of The Product For You!
