100G QSFP Active Optical Cables AOC Cable Module RoHS-6 Compliant
100G QSFP Active Optical Cables AOC Cable Module RoHS-6 Compliant
Specifications
Brand Name :
Optowix
Model Number :
MT1Q-AOCXX
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
T/T
Supply Ability :
10Kpcs
Delivery Time :
5-8 working days
Packaging Details :
ESD plastic case
Product Name :
100G QSFP Active Optical Cables AOC Cable Module
Optowix PN :
MT1Q-AOCXX
Description

100G QSFP Active Optical Cables AOC Cable Module

Features

• Multi rate of up to 25.78125 Gb/s per channel
• Complies with QSFP+ MSA form factors
• Hot-pluggable
• +3.3V Single power supply
• Low power consumption
• Case operating temperature
• Commercial: 0°C to +70°C

Applications

• 4x25.78125G Ethernet
• InfiniBand QDR, EDR
• Other optical links

Standards

• SFF-8636
• QSFP+ MSA


Ordering information

Part Number Product Description
MT1Q-AOC01 100G QSFP28 Active Optical Cable 1Meter
MT1Q-AOC03 100G QSFP28 Active Optical Cable 3Meters
MT1Q-AOC05 100G QSFP28 Active Optical Cable 5Meters
MT1Q-AOC07 100G QSFP28 Active Optical Cable 7Meters
MT1Q-AOC10 100G QSFP28 Active Optical Cable 10Meters
MT1Q-AOC15 100G QSFP28 Active Optical Cable 15Meters
MT1Q-AOC20 100G QSFP28 Active Optical Cable 20Meters
MT1Q-AOC25 100G QSFP28 Active Optical Cable 25Meters
MT1Q-AOC30 100G QSFP28 Active Optical Cable 30Meters
MT1Q-AOC50 100G QSFP28 Active Optical Cable 50Meters


Absolute Maximum Ratings

Parameter Symbol Min Typ Max Unit Ref.
Maximum Supply Voltage Vcc1,V ccT,Vc cRx -0.5 3.6 V
Storage Temperature Ts -40 85 °C 1
Case Operating Temperature TOP 0 70 °C
Relative Humidity RH 0 85 % 2
Notes:

1. Limited by the fiber cable jacket, not the activeends.
2. Non-condensing.


Electrical Characteristics(TOP = 0 to 70 C, Vcc = 3.3 ± 5% Volts)

Parameter Symbol Min. Typ. Max. Unit Ref.
Supply Voltage Vcc1, VccTx, VccRx 3.15 3.45 V
Supply Current Icc 750 mA
Transmitter(per Lane)
Input different impedance Rin 90 100 110 Ω
Single ended input voltage tolerance VinT -0.3 4.0 V
Single ended data input swing Vin,pp 200 1000 mV
Receiver (per Lane)
Output different impedance Rout 90 100 110 Ω
Single ended data output swing Vout,pp 200 1000 mV
Single-ended output voltage VoutR -0.3 4.0 V
