Optowix DAC Cable 10G SFP+ Passive Copper Cable Assembly Module
Optowix DAC Cable 10G SFP+ Passive Copper Cable Assembly Module
Specifications
Brand Name :
Optowix
Model Number :
MF1H-DACXX
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
T/T
Supply Ability :
10Kpcs
Delivery Time :
5~8 working days
Packaging Details :
ESD plastic case
Product Name :
10G SFP+ Passive Copper Cable Assembly Module
Optowix PN :
MF1H-DACXX
SpeedRate :
10G
Distrance :
3m~10m
Description

10G SFP+ Passive Copper Cable Assembly Module Optical Transceiver Module

Features

· Up to 10 Gb/s bi-directional data links

· Compliant with 10GFC

· Compliant with SFF-8431

· AC coupled inputs and outputs

· 100 Ohm differential impedance

· Enhanced EMI design

· Single power supply 3.3V

· Operating temperature range: 0◦C to 70◦C

Applications

· 10G Ethernet

· 10G Fiber Channel

· Serial Data Transmission

Standards

· SFF-8431

· IEEE 802.3ae

Ordering information

Part No. Description Gauge Length
MF1H-DACxx-30 SFP+ Passive Direct Attach Copper Black Cable Assembly,without MCU, xx≤3 30AWG ≤3m
MF1H-DACxx-28 SFP+ Passive Direct Attach Copper Black Cable Assembly,without MCU,xx<5 28AWG <5m
MF1H-DACxx-24 SFP+ Passive Direct Attach Copper Black Cable Assembly,without MCU,xx≤10 24AWG

≤10m

Description

· Optowix’s 10G passive cable uses shielded high-speed differential cables,compliant with 10 Gigabit Ethernet standards and SFP Multi-Source Agreement (MSA) standards, supports 10G transmission rates, and is backward compatible with 1G rates.SFP 10G passive cable is the preferred solution for short-distance applications. It is widely used for data transmission between data centers and cabinets or adjacent cabinets. Its biggest feature is low cost, ultra-low power consumption (less than 0.1 watt) and high reliability.

Absolute Maximum Ratings

Parameter Symbol Min. Typ Max. Unit Remarks
Data Rate DR 10.3125 1
Bit Error Rate BER 10-12
Operating Temperature Tc 0 - 70 °C 2
Storage Temperature TSTO -40 - 85 °C 3
Input Voltage Vcc 3.14 3.3 3.46 V 4
