24 12 Port Fibre Channel Switch Includes 12 16Gb/S Shortwave SFP SX CFW Core Switch
24 12 Port Fibre Channel Switch Includes 12 16Gb/S Shortwave SFP SX CFW Core Switch
24 12 Port Fibre Channel Switch Includes 12 16Gb/S Shortwave SFP SX CFW Core Switch
24 12 Port Fibre Channel Switch Includes 12 16Gb/S Shortwave SFP SX CFW Core Switch
Specifications
Brand Name :
Brocade
Model Number :
BR-6505-12-16G-0R
Place of Origin :
Beijing, China
MOQ :
1 pieces
Price :
$5,250 -5600/ piece
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Packaging Details :
box
ports :
24
transmission rate :
10/100/1000Mbps
communication mode :
Full-Duplex
switch capacity :
16Gbps
AC input :
85 V to 264 V ~5 A to 2.5 A
Warranty :
3 years
Description
Product Description
switch ethernet fiber optic BR-6505-12-16G-0R
The Brocade® 6505 Switch with Gen 5 Fibre Channel provides exceptional price/performance value, combining flexibility, simplicity, and enterprise-class functionality in an entry-level switch. Designed to enable maximum flexibility and reliability, the Brocade
6505 is configurable in 12 or 24 ports and supports 2, 4, 8, or 16 Gbps speeds in an efficiently designed 1U package. It comes
standard with a single power supply with integrated fans. A second, optional power supply provides additional redundancy for
increased resiliency.
model number
switch ethernet fiber optic BR-6505-12-16G-0R
Products Status
Stock
Ports
24
Communication Mode
Full-Duplex
Model Number
6505
Place of Origin
China
Lifecycle
Active
Frame buffers
8,192 dynamically allocated
Classes of service
Class 2, Class 3, Class F (inter-switch frames)
Access Gateway
Supports
Data traffic types
Fabric switches supporting unicast
Heat dissipation
24 ports at 338 BTU/hr
Input line frequency
47 Hz to 63 Hz
Size
Width: 437.64 mm (17.23 in.)
Height: 43.18 mm (1.7 in.)
Depth: 443.23 mm (17.45 in.)
Vibration
Operating: 0.5 g sine, 0.4 grms random, 5 Hz to 500 Hz Non-operating: 2.0 g sine, 1.1 grms random, 5 Hz to 500 Hz
Supported management software
HTTP, SNMP v1/v3 (FE MIB, FC Management MIB), SSH; Auditing, Syslog; Brocade Advanced Web Tools; Brocade Network Advisor SAN
Enterprise or Brocade Network Advisor SAN Professional/Professional Plus; Command Line Interface (CLI); SMI-S compliant;
Administrative Domains; trial licenses for add-on capabilities
Company Profile
Beijing Hengzheng TC Sci-Tech Co.,Ltd. is a trusted supplier of rovider of data communication products and information security products solutions,headquartered in Beijing, China, with over 16 years of industry experience since our founding in 2009. Products including but not limited to:
Network cards, Optical modules, High-speed cables, Switches, and Industrial control boards.

Our dedicated team (50+ employees) specializes in networking, storage, and connectivity solutions, ensuring global customers receive high-performance hardware at competitive prices, and a prompt 7*24h service to keep your business guaranteed.
