MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
Specifications
Brand Name :
HengzhengTC
Model Number :
HZ-8BMPOOM4-3M
Place of Origin :
China
MOQ :
1 pieces
Price :
US $ 128-300 / pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Packaging Details :
box
Polish Type :
UPC - UPC
Fiber Type :
OM4 50/125μm
Wavelength :
850/1300nm
Number Of Fibers :
8Fibers
Cable Outer Diameter (OD) :
3.0mm
Quality Assurance :
1 Year
Description
MPO fiber optic patch cord with 8-core OM4 multimode fiber and 0.25dB insertion loss for high-density data center applications
MPO fiber optic jumpers provide seamless transitions for multi-mode systems in data centers when upgrading data transmission rates. These high-performance jumpers are primarily used for internal cabinet connections, offering an economical and efficient alternative that eliminates time-consuming on-site termination work. Ideal for high-density fiber optic cabling in space-constrained data centers with demanding cable management requirements.
Technical Specifications
Category Details
Connector A US Conec MTP® Female Connector (Without Pins)
Connector B US Conec MTP® Female Connector (Without Pins)
Polish Type UPC - UPC
Optical Fiber (Corning) Corning ClearCurve®
Fiber Type

OM4 50/125μm
Wavelength 850/1300nm
Number of Fibers 8 Fibers
Polarity Polarity A
Cable Outer Diameter (OD) 3.0mm
Cable Jacket Plenum (OFNP)
Minimum Bend Radius (Fiber) 7.5mm
Minimum Bend Radius (Patch Cord) 20/10D (Dynamic/Static)
Connector Durability 500 Cycles
Tensile Strength (Long-term/Short-term) 90/180N
Insertion Loss

≤0.25dB
Return Loss ≥20dB
Attenuation @850nm

≤3.5dB/km
Attenuation @1300nm

≤1.5dB/km
Operating Temperature

0~60°C (32~140℉)
Storage Temperature

-10~70°C (14~158℉)

MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss

Packing & Delivery
MPO Fiber Optic Patch Cord With 8 Core OM4 Multimode Fiber 0.25dB Insertion Loss
FAQ
Q: Are you a trading company or manufacturer?
A: We are a manufacturer.
Q: How long is your delivery time?
A: Generally 2-5 days if goods are in stock, or about 10 days if not in stock (depending on quantity).
Q: Can you offer a better price? Any discount?
A: Yes, we offer quantity-based discounts. Larger quantities receive more attractive pricing.
Q: What is your warranty period?
A: 1. Different products have different warranties. 2. We provide comprehensive after-sales service including quality service and guidance. Contact us for specific warranty terms.
Q: What's the package?
A: Original packing with protective outer box to prevent damage during transportation.
