High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
High Performance IMU Inertial Measurement Unit 8*7cm Size For Navigation Guidance
Specifications
Place of Origin :
China
Brand Name :
Liocrebif
Certification :
GJB 9001C-2017
Price :
5000-25000CHY
MOQ :
1
Packaging Details :
Wooden box/Cardboard box/Container
Delivery Time :
2-4 weeks
Payment Terms :
T/T
Supply Ability :
10000
Model Number :
LKF-F3X80
Dimensions :
Ф8*7cm
Color&Classification :
LKF-F3X80
Brand :
Liocrebif
Output format :
RS422
Application :
Navigation guidance, Attitude measurement and control systems for small missiles and guided bombs
Original Place :
China
Description
Essential details
MOQ:1
Size:Ф8*7cm
Specification Number:LKF-F3X80
Product Introduction

Introduction

LKF-F3X80 inertial measurement unit is an inertial product developed for navigation guidance, attitude measurement and control systems of small missiles and guided bombs. The angular velocity and linear acceleration of the carrier motion provide information for the attitude and navigation control of the carrier, and the measurement results are output through the RS422 serial port.

By reducing the outer diameter of fiber to 135μm,Thin PM fiber solution decreases extremely the size of fiber coils and delivers outstanding precision performance in fiber coils, which is applied for miniaturization of FOGs. And the coils are wound precisely through quadrupole symmetry method.

The LKF-F3X80 plays a key role in navigation and positioning due to its highly accurate rotational measurement capabilities. It is widely used in aircraft, satellites and drones to ensure they maintain accurate positioning and navigation in the sky. This is critical for air rescue, weather forecasting and the stability of communications satellites.

Table 1 Performance parameters of LKF-F3X80 Three-axis FOG IMU

Fiber Optic Gyroscope

A

B

C

Bias Repeatability at Room Temperature (By times, by days) (º/h)

≤0.5

≤0.3

≤0.20

Bias stability at Constant Temperature (º/ h)

≤0.5

≤0.3

≤0.20

Scale Factor Repeatability at Room Temperature (ppm)

≤50

≤30

≤20

Scale Factor Asymmetry at Constant Temperature (ppm)

≤30

≤20

≤20

Scale Factor Nonlinearity at Constant Temperature (ppm)

≤30

≤20

≤20

Threshold (º/h)

≤0.5º/h

Angular Rate Range (º/s)

-500 to +500 º/s

Bandwidth (Hz)

100

Dimensions (mm)

Ф80*70

Weight (g)

780±20 (with accelerometer)

Operating Temperature (°C)

-40 to +65

Quartz Accelerometer

No.

Item

Technical Requirement

1

Range (g)

≥±40

2

Scale Factor Temperature Coefficient (ppm /°C)

≤100

3

Scale Factor Monthly Stability (ppm)

≤100

4

Bias (mg)

≤±7

5

Bias Temperature Coefficient (μg /°C)

≤100

6

Bias Monthly Stability (μg)

≤100

7

Second-order Nonlinear Coefficient (μg /g2)

≤20

8

Mounting angle (")

≤200

9

Outlook

No scratches, cracks, or corrosion

10

Isolate

≥20MΩ; (100V),25℃±5℃, humidity≤80%

Table 2 The electrical interface of the gyroscope uses J30-15ZK connector

LKF-F3X80-IMU/INS Output Definition

J30J-15ZK

Define

Note

5, 13

+24V

Inertia Combination

Power Supply

6, 7

+24V (ground)

1

T3+

Serial Port

2

T3-

3

R3+

4

R3-

11

T2+

IMU Data Output Serial Port

12

T2-

14

T1+

Debugging Serial Ports

15

T1-

9

R1+

10

R1-

Main Features

High Degree of Engineering, Highly Cost-Effective

Pure Solid-State Design with Strong Environmental Adaptability

Full Digital RS-422 Electrical Interface Output

Application

Navigation guidance

Attitude measurement and control systems for small missiles and guided bombs

Fig. 1 Dimensions of the external structure
