Low Cost Optical Amplifier , Serial Port Multiplexer Eight STM-16 Services OTU2S
Low Cost Optical Amplifier , Serial Port Multiplexer Eight STM-16 Services OTU2S
Specifications
Brand Name :
Fiberhome
Model Number :
FONST 1000 OTU2S
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 pc
Price :
To be negotiated
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 units
Delivery Time :
2-4 working week
Packaging Details :
Wooden Carton, Export Carton
Type :
Accesses eight STM-16 services
Dimension (Length×Width) (mm) :
368 × 30
Net Weight (kg) :
1.0
Max. Power Consumption (W) :
25
Description

Low Cost Optical Amplifier , Serial Port Multiplexer Eight STM-16 Services OTU2S

Overview

  • Specifications of Client Side Interfaces on the OTU2S Card
Item Unit Specification
Optical module type - 10 Gbit/s (multiple rates) 10 Gbit/s (multiple rates) 10 Gbit/s (multiple rates)
Target distance km 10 40 80
Transmitter at reference point S Operating wavelength range nm

1290 to

1330

1530 to

1565

1530 to

1565
Maximum -20 dB width nm 1.0 0.4 0.4
Minimum side mode suppression ratio dB 30 - -
Maximum mean launched power dBm -1 2 4
Minimum mean launched power dBm -6 -1 0
Minimum extinction ratio dB 6.5 8.2 9
Transmit signal eye pattern - ITU-T G.691 mask compliant
Receiver at reference point R Receiver type - PIN APD
Minimum sensitivity (BER ≤ 10-12) dBm -14 -17 -24
Minimum overload (BER ≤ 10-12) dBm 0 0 -7
Maximum reflectance of receiver, measured at R dB -27 -27 -27

  • Specifications of WDM Side Optical Interfaces on the OTU2S Card
Item Unit Specification
Source type and modulation format - DFB/MZ
Dispersion tolerance ps/nm 800
Transmitter at reference point S Maximum -20 dB width nm 0.3
Minimum side mode suppression ratio dB 35
Maximum mean launched power dBm 3
Minimum mean launched power dBm -2
Minimum extinction ratio dB 10
Transmit signal eye pattern - ITU-T G.691 mask compliant

Receiver at reference point

R

 Minimum sensitivity (BER ≤ 10-12) dBm -17 (PIN)
Minimum overload (BER ≤ 10-12) dBm 0 (PIN)
Maximum reflectance of receiver, measured at R dB -27

Mechanical Parameters

Card Panel Dimension (Length×Width) (mm) Net Weight (kg)
OTU2S 368 × 30 1.0

Power Consumption

Card Maximum Power Consumption (W)
OTU2S 25
