Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
Specifications
Brand Name :
UNIFIBER-OEM
Model Number :
sc apc g657b3 armored fiber patch cord
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000pcs/day
Delivery Time :
3~5 business days
Packaging Details :
Carton box
Product :
sc apc to sc apc simplex os2 g657b3 fiber patch cord
Connector :
SC/APC to SC/APC
Fiber Type :
G657B3
Cable Jacket :
LSZH White
Cable Diameter :
3.0mm Armored
Length :
Customized
Application :
FTTH
Description

sc apc to sc apc simplex os2 g657b3 armored fiber patch cord is a kind of patch cord but assembly with ftth drop cable. Used widely in Fact plate, terminal box, ONU tec. For ftth drop cable patch cords, normally use G657A1/G657A2 or G657B3 fiber with LSZH jacket, G657B3 fiber with the smallest minimum bending radius of 5mm, which become more and more popular for last 100m cable in FTTH project.

Features:
Excellent mechanical endurance

Good in repeatability and exchange

Low insertion loss and back reflection loss
Green Production, CE, RoHS Standard

Application:

FTTX Solution
Telecommunications
CATV, LAN, MAN, WAN

Test &Measurement

Specification

item SM(Single Mode) MM(Multimode)
Fiber Cable Type G652/G655/G657 OM1 OM2/OM3/OM4
Fiber Diameter (um) 9/125 62.5/125 50/125
Cable OD (mm) 0.9/1.6/1.8/2.0/2.4/3.0
Endface Type PC UPC APC UPC UPC
Typical Insertion Loss (dB) <0.2 <0.15 <0.2 <0.1 <0.1
Return Loss (dB) >45 >50 >60 /
Insert-pull Test (dB) <0.2 <0.3 <0.15
Interchangeability (dB) <0.1 <0.15 <0.1
Anti-tensile Force (N) >70
Temperature Range (℃) -40~+80

Simplex OS2 G657b3 Armored Fiber Patch Cord Single Mode SC APC
