Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
Specifications
Brand Name :
UNIFIBER-OEM
Model Number :
mini SC
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000pcs/day
Delivery Time :
3-5days
Packaging Details :
PE bag
Connector :
mini SC
Cable Jacket :
LSZH,TPU,PE
Cable Diameter :
4.8mm or 7mm
Cable Mode :
GJFJH
Cable Length :
1/3/5/10m or Customized
Application :
FTTH
Description

Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies

Mini SC Connector have been designed and tested to meet the stringent requirements necessary in environmental protection for outdoor application to ensures reliability and compatibility with a wide range of SC, LC and MPO connectors currently on the market. Also have the functions of waterproof, dustpoof and fireproof,This connectors widely used in FTTA, Base station.with could be terminated with self-supporting flat drop cable or 4.8/7.0mm round cable. All the cables are LSZH sheathed.which could be made with any customized length.

Features

IP67 water and dust protection

Guide mechanism, can be blinded with one hand, simple and quick, connect and install
Seal design: It is waterproof, dust-proof, anti-corrosion and so on.

Compact size, easy to operate, durable
Easy connection to hardened adapters on terminals or closures
Reduce welding, connect directly to achieve interconnection
Spiral clamping mechanism ensures long-term reliable connection


APPLICATION
FTTx wiring project

waterproof fiber equipment SC port

Fiber optic communications in harsh outdoor environments
Outdoor communication equipment connection
Remote wireless base station

ype SM-UPC SM-APC MM-UPC
Typical MAX Typical MAX Typical MAX
Insertion loss ≤0.1dB ≤0.3dB ≤0.15dB ≤0.3dB ≤0.05dB ≤0.3dB
Return loss ≥50dB ≥60dB ≥30dB
Durability 500 mating cycles
Working temperature -40 to + 85℃

Huawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assembliesHuawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assembliesHuawei mini SC/apc to SC/apc Pre Connectorized Drop Cable Patch Cord, Outdoor waterproof fiber optic cable assemblies
