ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
Specifications
Brand Name :
UNIFIBER-OEM
Model Number :
ODVASC
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000PCS/DAY
Delivery Time :
3-5days
Packaging Details :
PE bag
Insertion Loss :
0.25dB
Connector :
SC/LC/MPO
Return Loss :
APC>65dB
Waterproof :
IP67
Application :
FTTA
Installation :
Fiberhub enclosure
Description

ODVA SC Bulkhead Fiber Optic Adaptor With dust cap, waterproof IP 67 for fiberhub terminal box enclosure

The ODVA SC waterproof adapter is used for harsh industrial or outdoor environments, mounts case side to panel or enclosure, female simplex singlemode SC pass-thru receptacle to female simplex SC connectors, quick-release quarter-turn bayonet locking to cable shield, gasket seals provide IP67 rated water tight and dust free protection.

Features:

Used to connect either PC or UPC polished SC Fiber cables.
Plastic body provides a light weight yet durable solution.
Stainless steel mounting clips allow for easy snap in installation.
Ceramic alignment sleeve supports Singlemode and Multimode applications.

Application

Fiber-to-the-Antenna (FTTA)

Automation and Industrial Cabling
Surveillance Systems

Broadcast

Military Communications
BBU, RRU, RRH, LTE


Operating Performance 		Outdoor SC ODVA Waterproof Adapter
PC APC
Insertion Loss (dB) < 0.3 < 0.3
Durability (500 Mating) (dB) < 0.1 < 0.1
Operation Temperature (°C) -40 to 80 -40 to 80
Retention Force (N) 200-600 200-600
Tensile Strength (kgf) 10 10
Housing Material PC PC
Mounting Style Screw/Clip Screw/Clip
Sleeve Alignment Material Ceramic (Grade A) Ceramic (Grade A)
Housing Color Black Black

ODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box EnclosureODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box EnclosureODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box EnclosureODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box EnclosureODVA SC Bulkhead Fiber Optic Adaptor Waterproof IP67 For Fiberhub Terminal Box Enclosure
