Specifications
Brand Name :
Fujikura
Model Number :
FSM-66S
Certification :
CE/Rosh/ISO9001
Place of Origin :
Japan
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
usually 7 working days after payment or depends on quantity
Packaging Details :
stander packing
product Name :
Core alignment fusion splicer machine
Brand :
Fujikura
Model :
FSM-66S
Fiber type :
Single fiber
Fiber loss :
0.00dB-0.03dB
Screen :
Touch Screen
Splicing time :
7 seconds
Warranty :
2 Years
Description
Fujikura FSM-66S fusion splicer japan fujikura fsm 66S core alignment fiber splicign machine
FSM 66S/87S/88S is a fusion splicer with a high precision lenses, which provide an accurate core-to-core alignment. Also, these lenses allow the splicer to discriminate between fiber types.The 88S possesses advanced image processing technology which analyzes the profile of the fiber image as a brightness pattern. The tool finds the true core position and achieves the consistent lower splice loss. The device features fiber discrimination function: it automatically identifies the optimum arc discharge parameters in accordance with the fiber type.

Features:

Core alignment technology
Advanced image processing technology
Fiber discrimination function
Fiber alignment method
Active core alignment
Fiber count
Single fiber
Fiber type
Single mode, Multi mode
Cladding dia.
80 to 150μm
Sheath clamp
Coating dia. : Max. 3,000μm
Cleave length : 5 to 16mm
Splice loss
G.652: 0.02dB, G.651: 0.01dB, G.653: 0.04dB, G.655: 0.04dB, G.657: 0.02dB
Splice time
SM FAST mode: 7 to 9sec.
AUTO mode: 14 to 16sec.
Protection sleeve
Length: 66mm; dia.: Max. 6.0mm before shrinking
Heat time
60mm slim mode : 9 to 10sec.
60mm mode : 13 to 15sec.
Fiber tensile test force
Approx. 2.0N
Electrode life
5,000 splices
Dimensions
170W x 173D x 150H (mm)
Weight
2.8kg including battery
Environmental condition
Operate: temperature : -40 to 80 degree; Humidity: 0 to 95% non-condensing;
Storage: temperature : -10 to 50 degree; Humidity: 0 to 95% non-condensing;
Altitude: Max. 5,000m
AC adaptor Input
AC100 to 240V, 50/60Hz, Max. 1.5A
Battery
Rechargeable Lithium Ion
Output Approx. DC14.4V / 6,380mAh Capacity 300 splice and heat cycles
Temperature Recharge : 0 to 30 degree,
Storage : -20 to 30 degree
LCD monitor
TFT 5 inches with touch screen
Magnification
200 to 320x Illumination
Illumination
LED lamp
Interface
PC: USB 2.0 Mini B type
External LED lamp: USB2.0 A, Approx. DC5V, 500mA
Ribbon Stripper: Mini DIN 6pin DC12V, Max. 1A
Wireless: Bluetooth 4.1 LE
Data storage
Splice mode: 100; Heat mode: 30;
Splice result: 20,000; image 100 images
