Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Compact 3D Crystal Engraving Machine for Custom Crystal Gifts
Specifications
Brand Name :
Perfect Laser
Model Number :
PE-DP-5050
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
500 sets/per/month
Delivery Time :
7-12 Working Days
Packaging Details :
Sea-Worthy Packing or Air-Worthy Packing
Product Name :
Desktop 3D Crystal Laser Engraving Machine
Laser Source :
5W UV Solid State Laser
Laser Wavelength :
355nm
Engraving Range :
50*50*80mm
Standard Lens :
100mm
Cooling Method :
Air Cooling
Supported File Formats :
BMP, JPG, DXF, OBJ, STL
Applicable Materials :
Crystal, glass, acrylic and other internal carving and metal surface carving
Description
Perfect Laser High Precision 3D Crystal Laser Engraving Machine for Crystal Glass Internal Engraving
(Medol: PE-DP-5050)
★ Product Introduction

The 3d laser engraving machine is a compact and high-precision system designed for internal engraving inside transparent materials such as crystal and glass. It adopts high-quality UV laser technology combined with high-speed optical scanning to achieve detailed 3D imaging inside the material without surface damage.

The PE-DP-5050 3d crystal laser engraving machine is built for commercial applications, featuring stable performance, low maintenance requirements, and efficient operation. With a working area of 50*50*80mm (optional 70*70*50mm), it is ideal for customized production and small-batch engraving businesses.

★ Product Features
1. UV Laser Source

Uses a 5W UV laser with high-frequency operation up to 40K Hz, providing stable engraving performance for detailed crystal work.

2. Fast Engraving Speed

Achieves engraving speeds of up to 200,000 points per minute, improving productivity for custom orders.

3. Dual Processing Functions

This 3d crystal engraving machine supports both 3D internal engraving and surface marking, expanding its application range.

4. Precision Control

With 0.01mm accuracy, the machine delivers detailed and clear 3D images inside crystal materials.

5. Wide File Compatibility

Supports BMP, JPG, DXF, OBJ, STL formats, making it easy to integrate into different design workflows.

6. Compact Structure & Easy Operation

Designed with a modular system, air cooling, and stable motion control for reliable operation and simple maintenance.

7. Flexible Power & Environment Adaptation

Operates with 110-220V, 50/60Hz, suitable for different regions, with recommended working conditions of 10–35°C and humidity below 85%.

★ Application
  • Suitable for engraving on crystal, glass, and acrylic materials
  • Applied in gift customization, tourism markets, photography studios, and advertising industries
  • Used for producing 3D portraits, souvenirs, commemorative items, and decorative products

Compact 3D Crystal Engraving Machine for Custom Crystal Gifts

★ Technical Data
Product Name Desktop 3D Crystal Laser Engraving Machine
Model PE-DP-5050
Laser Source 5W UV Solid State Laser
Laser Wavelength 355nm
Maximum Operating Frequency 40K HZ
Maximum Engraving Range 50*50*80mm, optional 70*70*50mm
Standard Lens 100mm
Accuracy 0.01mm
Top Speed 2 00,000 points/ min
Power < 300W 110-220v / 50Hz - 60Hz
Cooling Method Air Cooling
Environment Reduce dust and shock, temperature 10-35°C, humidity <85%
Supported File Formats BMP, JPG, DXF, OBJ, STL
Applicable Materials Crystal, glass, acrylic and other internal carving and metal surface carving
Machine Size 85 x 43 x 82 cm
Weight 75kgs
Laser Warranty 1 year
Software Perfect Laser self-developed software
★ Why Choose Perfect Laser
  1. Customer-orientated
  2. Wish to provide benefit to agents and customersFree pre-sales consulting, free sample service
  3. Life-long service
  4. Engineer overseas installation available12 hours quick feedback & after-sales service
  5. 10000+ customers choice
  6. Perfect Laser will be your reliable partner
★ Packaging & Delivery
  1. Prompt deliver at the very day.
  2. Well-trained and disciplined packing team.
  3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
  4. Sophisticated and professional logistic agent.
