High Speed Precision Laser Cutting Machine 0.03mm Positioning Accuracy 40m/Min
High Speed Precision Laser Cutting Machine 0.03mm Positioning Accuracy 40m/Min
Specifications
Brand Name :
QiHai
Model Number :
6060J
Certification :
CE, ISO
Place of Origin :
Foshan, Guangdong, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 set/month
Delivery Time :
50 days
Packaging Details :
wood
Cooling mode :
Water Cooling,Air Cooling,Water-cooling and protection system,Water Cooling for laser wood cutting machine price
Graphic format supported :
PLT,DXF,AI,DST,BMP
Cnc or not :
Yes,No,CNC for laser wood cutting machine price
Cutting thickness :
0-30mm,30mm,Materials,0-15mm ( depends on different materials,0-15mm
After-sales service provided :
Engineers available to service machinery overseas,No overseas service provided,Overseas service center available
Warranty :
1 Year
Color :
Blue and white
Function :
Cutting Metal Materials,Cutting Engraving Non-metal Materials,Laser Cutting Engraving Marking
Description
High Speed Precision Laser Cutting Machine 0.03mm Positioning Accuracy 40m/Min High Speed Precision Laser Cutting Machine 0.03mm Positioning Accuracy 40m/Min
QH-6060J High-speed Precision Laser Cutting Machine
Description​
The QH-6060J High-speed Precision Laser Cutting Machine is a specialized solution engineered for small-to-medium size high-precision sheet metal processing. It features a 600×600mm processing area and 60kg maximum loading weight, ideal for scenarios like precision component manufacturing (e.g., electronic parts, small hardware). Equipped with selectable laser power (1500W/3000W), it delivers consistent cuts on materials such as thin carbon steel, stainless steel, and aluminum. Its screw guideway transmission system, paired with ±0.03mm X/Y-axis positioning and repositioning accuracy, ensures exceptional cutting precision, while the 40m/min maximum linkage speed and 0.8G acceleration balance efficiency with stability. With overall dimensions of 1770×1650×1800mm and a 1200kg machine weight, it fits compact workshop spaces, operating on a standard 380V/50Hz power supply—making it a reliable choice for industries demanding both speed and precision.
Quick Detail​

Core Traits: High-speed (40m/min max linkage speed) + precision (±0.03mm positioning accuracy); screw guideway transmission for stable cuts.​

Key Specs: 600×600mm processing area, 60kg max loading; 1500W/3000W selectable laser power; 1770×1650×1800mm compact size.​

Application Fit: Ideal for precision electronic parts/small hardware; 380V/50Hz universal power, suits small workshops.

Technical Parameters

Specification Value
Processing Area 600 * 600mm
Maximum Loading Weight 60kg
Machine Weight 1200kg
Overall Dimensions 1770 * 1650 * 1800mm
Laser Power Range 1500W/3000W
X/Y-axis Positioning Accuracy ±0.03mm
X/Y-axis Repositioning Accuracy ±0.03mm
Maximum Linkage Acceleration 0.8G
Maximum Linkage Speed 40m/min
Transmission System Screw guideway transmission
Voltage Requirement 380V
Frequency 50Hz

Advantage​

Superior High-speed Precision: The combination of 40m/min maximum linkage speed (0.8G acceleration) and ±0.03mm X/Y-axis positioning/repositioning accuracy ensures fast processing without compromising cut quality—critical for manufacturing high-precision small components (e.g., electronic connectors, mini hardware parts).​

Stable Screw Guideway Transmission: Unlike traditional rack & pinion systems, the screw guideway transmission minimizes vibration during high-speed operation, reducing cut errors and extending the machine’s service life, while also simplifying routine maintenance.​

Compact & Space-Efficient Design: With overall dimensions of 1770×1650×1800mm and 1200kg weight, it occupies minimal workshop space, making it perfect for small-scale production facilities or workshops with limited area, without sacrificing processing capabilities.​

Flexible Power Adaptation: The 1500W/3000W selectable laser power allows users to match power to material thickness (e.g., 1500W for thin sheets, 3000W for thicker materials), optimizing energy consumption and cutting efficiency for diverse small-part processing needs.
