Specifications
Brand Name :
E-link
Model Number :
LNK-IMC10FST-MM
Certification :
ISO9001, CE, RoHS, FCC
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
Paypal, TT, Western Union, MoneyGram, Alipay
Supply Ability :
5000pcs per month
Delivery Time :
3~5 working days
Packaging Details :
Industrial Ethernet Media Converter Standard Export Package
Wavelength :
850nm
Transmission type :
Base band
Connector :
1x RJ45 10Base-T
Optical Port :
Optical Port
Input Power :
12~48VDC, 2-pin terminal block
Size :
95 x 70 x 30 mm
Weight :
0.25Kg
Casing :
Aluminum Case
Description

Mini Industrial 10BASE-T to 10BASE-FL Ethernet Media Converter

Overview

The LNK-IMC10FST Series is a rugged, industrial-grade media converter that seamlessly bridges

10Base-T Ethernet to 10Base-FL fiber optic networks, supporting both single-mode and multimode

fiber with transmission distances up to 20,000 meters.

Key Features:
✔ Industrial Durability – Operates in extreme temperatures (-40°C to 75°C) with a rugged aluminum

housing for harsh environments.
✔ Auto-Sensing UTP Port – Eliminates crossover cable hassles by automatically detecting and

adapting to MDI/MDI-X (works with straight or crossover cables).
✔Flexible Connectivity – Supports half-duplex & full-duplex modes for smooth integration with switches,

NICs, and legacy Ethernet devices.
✔ Easy Installation – DIN rail or distribution box mounting for quick deployment in industrial networks.

Why Choose This Converter?
- Extend 10 Mbps Ethernet over long distances with fiber reliability.
- No manual configuration—plug-and-play operation.
- Built for factory floors, outdoor installations, and demanding industrial applications.

Upgrade your network with E-link’s hardened fiber media converter—designed for performance, durability,

and hassle-free connectivity.

Features

► Interoperable with other 10Base media converters, 10Base, 10Base-T NICs, hubs or switches

► Complies with 802.3 10Base-T and 10Base-FL standards

► Supporting Quality of Service (QoS), ensuring the transmission of VoIP packets

► Supports 802.3x Flow control

► -40°C to 80°C (-40°F to 176°F) operating temperature.

► Supports Wall-mount and DIN-Rail installation

Application

Mini Industrial Fiber Optical Media Converter with 10BASE-T Ethernet and 10BASE-FL Network Ports

Techinical Indexes

Ethernet
Standards: IEEE 802.3
10 Base-T
10 Base-FL
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE802.3x Full duplex and flow control
Conversion Means: Store and Forward mode or Cut-Through mode
Forward Filter Rate: 14,880pps (10Mbps)
Wavelength: 850nm
Buffer Space: Built in 128Kb RAM for data buffer
Flow Control:

Full duplex: flow control;

Half duplex: back pressure
Cable Length:

50/125um or 62.5/125um Multi-mode duplex fiber optic cable for 10Base-FL

100 meters max. for UTP

2000 meters max. for fiber optic Multi-mode
Transmission type: Base band
Connection switch: 2-position 10Base-T switch on RJ-45 side (hub or W/S)
Interface
Connector: 1x RJ45 10Base-T
Optical Port: c
Electrical and Mechanical
Input Power: 12~48VDC, 2-pin terminal block
Power Consumption: 5W Max.
LED Indicators:
PWR: Power Status
ACT: Data LINK Status
TP: Ethernet Status
FL: Fiber LINK Status
Dimensions (WxDxH): 95 x 70 x 30 mm
Weight: 0.25Kg
Casing: Aluminum Case
Mounting Options: DIN-Rail / Wall-mount
Environmental
Operating Temperature: -40°C to 75°C (-40°F to 167°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
MTBF > 200,000 hrs
Regulatory Approvals
ISO9001, CE, FCC, RoHS

EMI:

EN55022:2010+AC: 2011, Class A

EN 61000-3-2: 2006+A1: 2009+A2: 2009

EN 61000-3-3: 2013

EN55024: 2010

EMS:

IEC 61000-4-2: 2008 (ESD)

IEC 61000-4-3: 2010 (RS)

IEC 61000-4-4: 2012 (EFT)

IEC 61000-4-5: 2014 (Surge)

IEC 61000-4-6: 2013 (CS)

IEC 61000-4-8: 2009 (PFMF)

Ordering Information

Model Description
LNK-IMC10FST-MM Mini Industrial 10BASE-T to 10BASE-FL Ethernet Media Converter, multi-mode, 2km, 850nm, ST
Mounting Options ► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
Power Options ► 24W/1A 24VDC Power Supply. Open Wire for Terminal Block
► Power Supply is to be purchased separately.
