Specifications
Brand Name :
E-link
Model Number :
LNK-M3011-SFP
Certification :
CE FCC RoHS ISO9001
Place of Origin :
China
MOQ :
1 pc
Price :
Please contact seller
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
10000 per mouth
Delivery Time :
5-10 working days
Packaging Details :
Ultra-Compact USB-Powered Gigabit Ethernet Media Converter SFP Media conversion Standard export package
Product name :
Ethernet Gigabit Media Converter
Power supply :
DC 5~15V (Type C)
Dimension :
78 x 27 x 18 mm
Power :
3W
Weight :
46g
Temperature :
-40-70℃
Description

Micro Mini 10/100/1000BASE-T to 100/1000BASE-X SFP Media Converter

Overview

LNK-M3011-SFP 10/100/1000Mbps adaptive Gigabit Ethernet media converter adopts

advanced switching technology and complies with IEEE802.3, IEEE802.3u, IEEE802.3z

and IEEE802.3ab standards. It supports the conversion between 10Base-T/100Base-TX/1000Base-T

and 100/1000Base-X, and realizes the conversion between electrical signals and optical signals.

It extends the transmission distance of copper cable network to 100 meters

This device supports multi-mode dual-fiber, single-mode dual-fiber and

single-mode single-fiber transmission, and is suitable for various network environments.

When connected to the computer USB port, the converter can automatically power off

when the computer is shut down, which is energy-efficient.

Technical Indexes

Parameter Specifications
Access mode 10/100/1000Mbps Gigabit Ethernet
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit Ethernet
Fiber Port SFP - 100/1000M adaptive
Wavelength 850nm/1310nm/1550nm (Based on SFP Module used)
Transmission distance

Fiber Cable: Depends on SFP Module

Category-5 twisted pairs: 100m
Port

One RJ45 port: for connecting with STP/UTP cat5/6 twisted pairs

One Optical port: SFP
Conversion means Media conversion
LFP Not Support
BER <10-9
MTBF 100,000 hours
LED indicator

PWR (Power supply)

TX (LINK100/1000, TP cable rate 100/1000M)

FX/ACT (Optical link action /TP cable packet forwarding action)
Power supply DC 5V (Type-C)
Power consumption <3W
Operating temperature 0~45ºC
Operating humidity 5%~90%
Maintaining temperature -40~70ºC
Maintaining humidity 5% ~ 90% non-condensing
Weight 46g
Dimensions (W x D x H)

78 x 27 x 18 mm

Ordering Information

Item Description
LNK-M3011-SFP Micro Mini Media Converter: 10/100/1000Base-T to 100/1000Base-X, SFP slot, not including SFP module, standalone, external power adaptor
