Specifications
Brand Name :
E-link
Model Number :
LNK-M3011-SFP
Certification :
CE FCC RoHS
Place of Origin :
Guangdong
MOQ :
1 pc
Price :
Please contact seller
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
10000 per mouth
Delivery Time :
5-10 working days
Packaging Details :
Fiber Ethernet Media Converter Standard export package
Product name :
Ethernet Media Converter
Power supply :
DC 5~18V
Dimension :
78 x 27 x 18 mm
Fiber Port :
SFP - 100/1000M adaptive
Weight :
46g
Power :
3W
Description

Micro Mini 10/100/1000BASE-T to 100/1000BASE-X SFP Media Converter

The LNK-M3011-SFP is an adaptive 10/100/1000Mbps Gigabit Ethernet media converter that seamlessly

interconnects copper and fiber networks. Compliant with IEEE 802.3, 802.3u, 802.3z, and 802.3ab

standards, it supports conversion between:

  • Copper (RJ-45): 10Base-T, 100Base-TX, 1000Base-T electrical signals over twisted pair.
  • Fiber (SFP): 100Base-FX, 1000Base-SX/LX optical signals.

This conversion dramatically extends network transmission distances from the 100-meter limitation of

copper cabling up to a maximum of 120 kilometers over fiber optics. The converter supports operation

over multi-mode dual fiber, single-mode dual fiber, and single-mode single fiber.
A key feature is its USB-powered operation. When plugged into a computer's USB port, the converter

automatically powers down with the computer, providing significant energy savings. This compact

design makes the LNK-M3011-SFP an ideal solution for "fiber-to-the-laptop" applications requiring

Gigabit fiber connectivity where local AC power is unavailable.

Technical Indexes

Parameter Specifications
Access mode 10/100/1000Mbps Gigabit Ethernet
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit Ethernet
Fiber Port SFP - 100/1000M adaptive
Wavelength 850nm/1310nm/1550nm (Based on SFP Module used)
Transmission distance

Fiber Cable: Depends on SFP Module

Category-5 twisted pairs: 100m
Port

One RJ45 port: for connecting with STP/UTP cat5/6 twisted pairs

One Optical port: SFP
Conversion means Media conversion
LFP Not Support
BER <10-9
MTBF 100,000 hours
LED indicator

PWR (Power supply)

TX (LINK100/1000, TP cable rate 100/1000M)

FX/ACT (Optical link action /TP cable packet forwarding action)
Power supply DC 5V (Type-C)
Power consumption <3W
Operating temperature 0~45ºC
Operating humidity 5%~90%
Maintaining temperature -40~70ºC
Maintaining humidity 5% ~ 90% non-condensing
Weight 46g
Dimensions (W x D x H) 78 x 27 x 18 mm

Ordering Information

Item Description
LNK-M3011-SFP Micro Mini Media Converter: 10/100/1000Base-T to 100/1000Base-X, SFP slot, not including SFP module, standalone, external power adaptor
