Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber
Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber
Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber
Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber
Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber
Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber
Specifications
Brand Name :
E-link
Model Number :
LNK-M24G-1F1
Certification :
CE, RoHS, FCC
Place of Origin :
China
MOQ :
1 pcs
Price :
negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, paypal,Credit Card
Supply Ability :
1000pcs/month
Delivery Time :
5-12working days
Packaging Details :
Standard Export Package
Compatible :
Compatible With DVB-ASI and AES10 (MADI)
Input :
2x 12G-SDI on BNC/1 x 24G-SDI 1*LC fiber
Supported Resolution :
HDTV 2160p/4k@120,8k@60, 1080P, 1080I, 720P
Operating Temperature :
-40℃～85℃
Dimensions (LxWxH) :
80 x 40 x 20 (mm)
Power :
5-15 VDC
Description

Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber

SDI Fiber Extender Advantages

► Each SDI channel includes 8-channel audio embedded

► Automatic cable equalization to ensure signal integrity

► Supports SMPTE ST-2083(24G) ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD) and ST-259(SD)

► Integrated Reclocker Locks to SMPTE Rates of 11.88Gbps*2, 5.94Gbps, 2.97Gbps, 1.485Gbps or Divide-by-1.001 Subrates and 270 M bps

► Directly compatible with 12G/6G/3G-SDI camera systems

► Terminal block power input for industrial application

► Supports hot swapping and hot plugging

► Full digital non-compression broadcast level transmission;

► super optic dynamic range and free of adjustment;

► fiber optic WDM/CWDM/DWDM technique;

SDI Fiber Extender Technical Indexes

Formats Supports UHD-2 or 24G UH D-SDI, SMPTE ST-2083(24G) ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD) And ST-259(SD)
Compatible Compatible With D VB-AS I and AES10 (MADI)
Input 2 x 12G-SDI on BNC
1 x 24G-SDI 1*LC fiber
Output 2x 12G-SDI on BNC
Supported Resolution HDTV 2160p/4k@120,8k@60, 1080P, 1080I, 720P
Resolution range 2160p/4k@120,8k@60Hz
Input cable specification ≤70m@12G SDI Bel den 1694A
Output cable specification ≤70m@12G SDI Belden 1694A
Optical transmission bandwidth 270MHz～12GHz
Power 5-15 VDC
Power Consumption 2 W (Max.)
Dimensions (LxWxH) 80 x 40 x 20 (mm)
Storage Temperature -40℃～80℃
Operating Temperature -40℃～85℃

Industrial Ethernet Media Converter Overview
LNK-M24G-1F1 Series Mini-type 24G-SDI Fiber Converter supports 2-Channel 12G Video (audio embedded) transmitted via fiber optical cable. E-link 24G Video over Fiber Converters includes one transmitter and one receiver for HDTV 2160p/4k@120,8k@60, 1080P,1080I, 720P.
Mini 24G-SDI to Fiber Converter with 24G-SDI 1*LC fiber

Ordering Information

Model Description
LNK-M24G-1F1-20 Mini-type 24G-SDI to Fiber Converter, 2*12G-SDI Video, 1*24G SFP(1*LC) Fiber Connector 20KM, including Transmitter and Receiver, used by pairs
