Specifications
Brand Name :
Wirecan
Model Number :
65+40
Certification :
CE
Place of Origin :
china
MOQ :
1 Set
Delivery Time :
30 works day
Raw Material :
copper wire
Bobbin Size :
8inch
Wire Material :
PVC Silicone
Suitable Material :
Copper,aluminium wire
Inlet Diameter :
9.5mm
Service :
1 year guarantee
Finished Wire Range :
Max.4
Insulation :
PVC,PP,LDPE,TPU
Advantage :
wire and cable coiling machines
Suit For :
copper stranding
Coil Inside Diameter :
130mm
Control Box :
International standard
Power Supply :
380V/50Hz
Drawing Speed :
24meter Wire Breakdown Drawing Machine
Conductor :
copper wire
Description
Discover the φ65+φ40 Tandem Extrusion Line, a cutting-edge high-efficiency LAN cable production solution. Designed and manufactured by Dongguan Wirecan, this advanced extrusion system is tailored for CAT5 and CAT6 network cable manufacturing, ensuring precision, stability, and high productivity.


Key Features:

1. High-Precision Insulation Extrusion - Ensures uniform insulation thickness for superior cable performance
2. PLC Intelligent Control System - Fully automated for real-time monitoring and production stability
3. High-Speed Production - Capable of producing cables at optimal efficiency for large-scale manufacturing
4. Advanced Quality Control - In-line measurement of eccentricity, diameter, and insulation thickness
5. Versatile Material Compatibility - Supports PVC, PE, XLPE, and LSZH insulation materials

High-Speed LAN Cable Extrusion Line | φ65+φ40 Tandem Extrusion Line
High-Speed LAN Cable Extrusion Line | φ65+φ40 Tandem Extrusion Line
Why Choose Our Extrusion Line?

Optimized Energy Efficiency - Reduces power consumption while maximizing output
Customizable Configurations - Adjustable settings to meet different cable specifications
Robust & Durable Design - Ensures long-term operation with minimal maintenance
Proven Industry Performance - Successfully implemented in multiple LAN cable manufacturing plants

High-Speed φ65+φ40 Tandem Extrusion Line for LAN Cable Production | Dongguan Wirecan

Production Line Components:

Component Description
Pay-Off Unit Holds and feeds the copper conductor into the extrusion line
Preheater Heats the conductor to improve insulation adhesion
Extruder (φ65+φ40) Dual-layer tandem extrusion for precise insulation
Cooling Water Tank Rapidly cools extruded cables for dimensional stability
Diameter & Eccentricity Tester Monitors and ensures uniform insulation thickness
Spark Tester Detects insulation defects and ensures electrical integrity
Tension Control System Maintains consistent cable feeding speed
Capstan Unit Provides pulling force to move the cable through the line
Take-Up Unit Collects the finished cable onto reels for easy handling



High-Speed LAN Cable Extrusion Line | φ65+φ40 Tandem Extrusion Line


High-Speed LAN Cable Extrusion Line | φ65+φ40 Tandem Extrusion Line

High-Speed LAN Cable Extrusion Line | φ65+φ40 Tandem Extrusion Line
