Hybrid Optical Fiber Composite Low-Voltage Cable OPLC for Power and Data Transmission
Hybrid Optical Fiber Composite Low-Voltage Cable OPLC for Power and Data Transmission
Hybrid Optical Fiber Composite Low-Voltage Cable OPLC for Power and Data Transmission
Hybrid Optical Fiber Composite Low-Voltage Cable OPLC for Power and Data Transmission
Hybrid Optical Fiber Composite Low-Voltage Cable OPLC for Power and Data Transmission
Hybrid Optical Fiber Composite Low-Voltage Cable OPLC for Power and Data Transmission
Specifications
Brand Name :
JQ or OEM/Customize
Model Number :
composite fiber cable OPLC
Certification :
ISO9001 CE ROHS FCC
Place of Origin :
Guangdong, China
MOQ :
2km
Price :
195USD~910usd
Payment Terms :
T/T,Alipay, Western Union, L/C
Supply Ability :
10000 km per month
Delivery Time :
6 days,it depends on order quantity
Packaging Details :
Wooden drum
Application :
Telecommunication/Data Center/FTTH
number of conductors :
2/4/24 core
Length :
customized service
Jacket material :
PE/HDPE/LSZH/MDPE
Name :
hybrid OPLC fiber optic cable
copper material :
100% pure copper
conductor material :
PVC/FRP
fiber type :
G652D/ G657A1/G657A2
jacket color :
black/red
Amored Material :
Aluminum Tape,Steel Tape
Fiber Optic Connector Color :
Blue/Green/Aqua/Black
Strength Member :
Two steel wire
Oem :
Yes
Connection Structure :
Composite Cable
Central Strength Member :
FRP
Conductor :
CCS Copper
Fiber Count :
2-144 CORES
Armor :
PE coated corrugated steel tape
Fiber Optic Connector :
LC/SC/FC/ST/MPO
Optical Fiber Material :
PMMA & copper power wires
Type :
Fiber Optic Cable, 14 18 22 awg
Sheath Material :
PVC/LSZH
Standard :
YD/T 901 / IEC 60794-3-10
Outer Diameter :
9mm
Arnored :
Aluminum Tape,Steel Tape
Cable Color :
Black/Yellow/Green/Customized
Bending Radius :
10D-20D
Insulation :
PVC jacket material
Color :
Black
Cable Diameter :
2.0mm-10.0mm
Description

What is a Hybrid Cable?


A Hybrid Cable, also called Optical Fiber Composite Low-voltage Cable (OPLC), is a new-generation solution that integrates both power supply and optical communication within a single cable structure. It combines low-voltage power conductors (0.6/1kV and below) with high-performance fiber optic cores, allowing the simultaneous delivery of electricity and ultra-fast data. This design makes it highly suitable for projects where both terminal power and information transmission are required.

Key Advantages of Hybrid Cable:

  • Dual Function Integration: Provides both power and data in one cable, reducing the need for separate wiring systems and simplifying project design.

  • Independent Structural Design: Power conductors and optical fibers are arranged separately, ensuring safety, stability, and easier installation, routing, and maintenance.

  • Cost & Time Efficiency: Photoelectric integration cuts down on material usage, installation labor, and overall infrastructure investment.

  • Smart Infrastructure Ready: Widely used in smart grid development, 5G base stations, FTTH (fiber-to-the-home) networks, intelligent buildings, and surveillance systems.

  • Reliable Performance: Supports stable power supply while ensuring high-speed, long-distance, and interference-free data transmission.
