Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price
Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price
Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price
Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price
Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price
Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price
Specifications
Brand Name :
JQ/OEM/Customize
Model Number :
ASU Cable/GYFFY
Certification :
ISO9001 ROHS CE-EMC FCC SDOC
Place of Origin :
Guangzhou,China
MOQ :
2km
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
4500KM Per Month
Delivery Time :
5-8 work days
Packaging Details :
wooden drum
Fiber count :
12 24 Core
Type :
Aerial
Span length :
80m or 100m
Fiber Model :
G652D, G657A1, G657A2
Sheath :
PE/LSZH/PVC/MDPE/HDPE
Strength member :
FRP/KFRP
Sheath color :
Black or Customize
Fiber Brand :
YOFC/Fiber Home/Fujikura/Corning
Description

Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price

ASU cable uses a stranded loose-tube design. The 250μm fibers are housed in high-modulus PBT tubes, which are stranded around a central FRP non-metallic strength member to form a compact core. The core is filled with water-blocking compound and protected with a thin PE sheath.

Features

  • Compact structure and lightweight design

  • Dual FRP strength members for enhanced tensile performance

  • Optional gel-filled or gel-free structure for reliable waterproofing

  • Cost-effective with high fiber density

  • Suitable for short-span aerial installation and duct laying

Optical Characteristics

Items Unit Specification
G652D
Mode Field Diameter 1310nm um 9.2±0.4
1550nm um 10.4±0.5
Cladding Diameter um 124.8±0.7
Cladding Non-Circularity % ≤0.7
Core-Cladding Concentricity Error um ≤0.5
Coating Diameter um 245±5
Coating Non-Circularity % ≤6.0
Cladding-Coating Concentricity Error um ≤12
Cable Cutoff Wavelength nm acc≤1260
Attenuation(max.) 1310nm dB/km ≤0.36
1550nm dBkm ≤0.22

Technical parameter


Cable Core		 Unit 2F 4F 6F 8F 10F 12F
No. Of Tubes 1 1 1 1 1 1
No. Of fibers core 2 4 6 8 10 12
Fiber Counts in tube core 2 4 6 8 10 12
Cable Diameter mm 6.6±0.5 6.8±0.5
Cable Weight Kg/km 40±10 45±10
Allowable tensile Strength N Span=80,1.5*P
Allowable crush resistance N 1000N
Operation temperature ℃ -20℃ to +65℃

Two FRP Aerial 12 Core ASU 80 Drop Fiber Optic Cable GYFFY Outdoor FTTH Cable Factory Price

FAQ

1. Are you a trading company or manufacturer?
We are a professional manufacturer with over 10 years of experience in fiber optic cable, drop cable, and patch cord production. Our factory is located in Guangzhou, and you are always welcome to visit.

2. How is the product quality ensured?
Every fiber is fully tested before shipment. After price confirmation, free samples can be provided for quality checking.

3. Do you accept small orders?
Yes, small orders are welcome. We support new projects and understand that many businesses start with small quantities.

4. What is the delivery time?
Generally 3–7 working days, depending on the order quantity. We will arrange shipment as soon as your payment is received.

5. Do you offer OEM service?
Yes, OEM is available. We can print your logo and customize according to your requirements.
