Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Specifications
Model Number :
Fiber Cable
Type :
Fiber Cable
Place of Origin :
Zhejiang, China
Brand Name :
oem
Number of Conductors :
≥ 10
Model NO. :
Fiber cable
Core :
Multicore
Certification :
RoHS, CE, ISO9001
Sheath Material :
PVC or LSZH
Fiber Mode :
fiber cable outdoor
Cable Structure :
Bow Type Tight Buffer
Reinforcer :
FRP/Steel Wire
Operating Temperature :
-50 ~ +60 °C
Package :
Drum
Supply Ability :
1000 Kilometer/Kilometers per Month
MOQ :
30 kilometers
Price :
$1.00/kilometers 30-499 kilometers
Description
Products Description
Fiber Optic Cable Fiber
The structure of GYTA53 optical cable is to connect 250 μ The optical fiber is inserted into a loose tube made of high modulus material, and the loose tube is filled with waterproof compound. The center of the cable core is a metal reinforced core, and for certain numbers of optical cables, a layer of polyethylene (PE) needs to be extruded outside the metal reinforced core. The loose sleeve (and filling rope) is twisted around the center to strengthen the core and form a compact and circular cable core. The gaps inside the cable core are filled with water blocking fillers. After being longitudinally wrapped with plastic coated aluminum strip (APL), a layer of polyethylene inner sheath is extruded, and after being longitudinally wrapped with double-sided plastic coated steel strip (PSP), a polyethylene sheath is extruded to form the cable.
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design





Characteristics
* ● Has good mechanical properties and temperature characteristics
● Loose casing material itself has good water resistance and high strength
● The tube is filled with special oil paste to protect the optical fiber
● PE sheath has good resistance to
ultraviolet radiation
● Good pressure resistance, suitable for pipeline or direct buried wiring
● Adopt the following measures to ensure the waterproof performance of the cable:
a ：single steel wire center reinforcement core
b ：Loose tube filled with special waterproof compound
c ：Complete cable core filling
d ：inner sheath
e ：Double-sided Plastic-aluminum tape (APL) moisture barrier
f ：Plastic coated corrugated steel strip
g ：Good water blocking material to prevent longitudinal water seepage of optical cable




Product Application

● Suitable for long-distance communication and inter-office communication.
● Laying conditions: overhead, pipeline, directly buried.
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
item
value
Model Number
outdoor fiber optic cable
Type
Fiber Optic Cable
Place of Origin
China
Zhejiang
Brand Name
OEM
Use
FTTH
Warranty Time
20 years
Network
None
Fiber Specifications
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
Outdoor Loose Sheath GYTA53 Fiber Optic Cable with Twisted Reinforced Armored Design
1. Are you a manufacturer or trade company?

We are the manufacturer with nearly 20 years' history.

2. What is your fiber brand ?

Our fiber brand include : YOFC, Corning, Fiber Home, J-fiber, POFC

3. What is your main product ?

Our main product is Fiber Optic Connector, Fiber Optic Adapter, Fiber Optic Attenuator, Fiber Optic Patch Cord and Fiber Terminal
Box, except that, we have very good prices for part of fiber tools!

4. How can we place order?

After we made agreement on the product parameters, we will make proforma invoice for your confirmation, when we got your advance
payment (deposit) we will arrange the production and delivery. If you have your own ship forwarder, we will use your ship
forwarder to delivery goods; if you don't have ship forwarder, we can ship them by our agent shipping company which can offer very
competitive freight cost!

5. What is the quality for your product?

All of our product are with high quality, we promise 100% recall policy if they are unqualified, we can write it into our
contract!

6. How do you arrange the shipping?

Solution A: Fibconet take care of everything. Clients only need to collect cargo in local or wait cargo delivery to their office.
There are two types of shipping methods available, by sea and by air (Express courier - FedEx/ DHL/UPS/TNT/EMS, we can ship them
according to your express account or ship them by our agent company, the delivery time is about four days).
Solution B: Clients assign a Shenzhen logistic company to do the shipping, Fibconet follow the company's instructions and finish
the shipping.

7. How can you guarantee the delivery time?

1. To avoid the delay, we have built a complete and professional procedure system from production to the deliver and have rich
experience. We can regulate the penalty clause in the contract for the late delay.

8. What's your best price for your passive fiber optic product?

Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the
time.

9. What is your quality control for your fiber optic product ?

1. Source Guarantee. We have our own long-term cooperation raw material suppliers. All the products are ROHS certificated and
satisfy exporting quality level demand.
2. Quality Test. It runs through the whole process from the raw material to finished product, such as package, surface, physical
test, optical test. They are 100% tested.
3. Optical Test. Our products are strictly tested in accordance with IEC and ITU standard.
4. We have 30% spot test by Quality Assurance Department after the products finished.

10. Why choose Fibconet Fiber Optic to cooperate?
1. We have first-class production line and strict quality management system.
2. We have professional procedure system and big production capacity to guarantee fast delivery and on time shipment.
3. We can provide the most competitive price to meet your budget.
4. We also design and innovate the new products based on our rich experience .
5. We have professional team to provide comprehensive one-stop service for you.

Please always feel free to contact us for any questions, it's our honor to be on service of you!
