Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Modular Operating Room Laminar Flow Ceiling System with ISO Class 5 Airflow, Integrated Medical Gas Supply, and Energy-Efficient EC Fans
Specifications
Cleanliness Class :
ISO Class 5 (Class 100)
Airflow Type :
Vertical Unidirectional Laminar Flow
Noise Level :
≤48 dB(A) at 1m distance
Medical Gas Ports :
O2, N2O, Medical Air, Vacuum, AGSS (up to 6 ports)
Model Number :
YN-OPM-16
Place of Origin :
Guangdong, China
HEPA Filter Efficiency :
≥99.995% at 0.3μm MPPS
Supply Ability :
5000 Sets per Month
Air Velocity Range :
0.25-0.45 m/s (adjustable)
Payment Terms :
T/T,L/C,Western Union,D/A,D/P
Delivery Time :
20-30 working days after deposit
Packaging Details :
Custom plywood
Lighting Integration :
LED Surgical Light Mounting Points Included
Certification :
ISO，CE
Price :
USD 2800-6500 / Set
Control Method :
PLC Touch Screen with BACnet Protocol
Brand Name :
Yaning
MOQ :
1 Set
Description
Modular Operating Room Laminar Flow Ceiling System with Integrated Medical Gas Supply Unit
Modular Operating Room Laminar Flow Ceiling System with Integrated Medical Gas Supply

The YN-OPM-16 is a complete ceiling solution that combines advanced laminar airflow technology with fully integrated medical gas supply and surgical lighting provisions. Designed as a turnkey module, it dramatically reduces on-site installation complexity while delivering ISO Class 5 cleanroom performance at the surgical site.

Key Features
  • All-in-One Ceiling Module: Integrates HEPA filtration plenum, laminar flow diffuser, medical gas terminal units, and LED lighting into a single pre-fabricated ceiling cassette — eliminating the need to coordinate between multiple suppliers.
  • ISO Class 5 Laminar Airflow: H14 HEPA filters with ≥99.995% efficiency at 0.3μm MPPS deliver ultra-clean vertical unidirectional airflow directly over the operating table, maintaining a sterile surgical zone compliant with ISO 14644-1 Class 5.
  • Built-in Medical Gas System: Pre-plumbed copper piping with certified gas-specific terminal units for O₂, N₂O, medical air, vacuum, and AGSS — tested to HTM 02-01 standards before factory shipment.
  • Customizable Layout: Ceiling dimensions, gas port positioning, and lighting arrangement can be fully customized to match your operating room architectural plans and surgical discipline requirements.
  • Energy-Efficient EC Fan Array: Electronically commutated (EC) plug fans with variable speed control maintain precise airflow while reducing energy consumption by up to 40% compared to conventional AC fan systems.
One-Stop Project Delivery
This ceiling system is part of our complete modular operating room package. We handle everything from CFD airflow simulation and 3D BIM modeling during the design phase, through factory pre-assembly testing, to on-site commissioning and performance validation. Our technical team provides installation supervision and IQ/OQ documentation as standard, ensuring your new operating room is ready for clinical use with minimal downtime.
