2.54mm Swiss Machine Rounded Female Header 4pin 16pin 20pin 32pin 40pin Round Pin Strip Dual Single Row Connector Plug Socket

Product Description

Overview

The 2.54mm Swiss Machine Rounded Female Header​ is a break-away strip built from turned brass tubes​ pressed into a PPS UL94 V-0 housing – not stamped square contacts. Each round receptacle grips both standard 0.64mm square male headers and 0.64mm round machine pins with uniform normal force, eliminating the "loose square socket" failure common in cheap strips. Supplied as a 40-pin single-row strip (101.6 mm) with score lines, snappable to 4/16/20/32/40; dual-row 2×n also tooled.

Application Industries

• Dev boards / eval kits​ – Arduino GPIO extender, Raspberry Pi HAT header, STM32 Nucleo baseboard (SparkFun PRT-00743 use case)

• Industrial PCB​ – PLC I/O daughter cards, DIN rail controller backplane, sensor breakout

• Test & measurement​ – fixture interconnect, ATE probe sockets, burn-in boards

• Medical / lab​ – patient-monitor sub-board, analyzer plugin modules (gold-flash version)

• Legacy equipment repair​ – replacing worn square-female strips on 1990s–2010s instruments

• Audio/synth DIY​ – Eurorack power header, CV/Gate bus (round pin retains better under vibration)

Customization Options

• Pin count: 4/16/20/32/40 (1×n) · 2×4–2×40 (2×n)

• Row: single/dual/triple

• Mount: straight THT (8.5/10.0/11.96 mm tail) / right-angle / SMT

• Contact: brass (default) / phosphor bronze

• Plating: gold flash / 30µ" / 50µ" + Ni / full tin / selective

• Housing: PPS black (default) / PA9T natural/colored PBT

• Receptacle depth: 3.0 mm / 6.0 mm

• Packing: loose strip/tube / tape-on-reel (SMT)

Step Custom Process

1. Requirement Collection → 2. Technical Evaluation & Quotation → 3. 3D Drawing Review & Confirmation → 4. Mold / Tooling & Prototype → 5. Sample Test (contact R, retention, reflow) & Approval → 6. Mass Production → 7. Final QC & Shipment.
