Double Roller Granulator for NPK Compound Fertilizer Production with 12-15 Tons Per Hour Capacity and Dry Powder Granulation
Double Roller Granulator for NPK Compound Fertilizer Production with 12-15 Tons Per Hour Capacity and Dry Powder Granulation
Specifications
Brand Name :
Shenghong
Model Number :
SDZ series
Certification :
BV, SGS, ISO
Place of Origin :
Zhegzhou, Henan Province China
MOQ :
1 Piece
Price :
can be negotiated
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
200 Sets Per Month
Delivery Time :
10-15 working days
Packaging Details :
Container or Plywood Box
Capacity :
12-15 Tons Per Hour
Service :
Long Term
Usage :
Making Fertilizer Granules
Raw Material :
NPK,Urea, ammonium nitrate, etc.
Installation :
Engineer guided
Function :
Making NPK Compound Fertilizer
Granules Shapes :
Ball Shape
Guarantee :
12 months
Description
Bentonite Cat Litter Production Line Granules Double Roller Granulator Making Machine

The SDZ series roller press granulator is an extrusion-based fertilizer granulating equipment designed for producing NPK compound fertilizer of various concentrations. This versatile machine is widely applied in fertilizer processing, feed production, and chemical industries for granulation and processing of powder materials.

The granulator accommodates a wide range of raw materials including ammonium carbonate, ammonium chloride, ammonium sulfate, ammonium nitrate, ammonium phosphate, magnesium silicate, zinc sulfate, and phosphorus pentoxide. The finished granules produced are of excellent quality, with low moisture content when prepared from dry powder.

Double Roller Granulator for NPK Compound Fertilizer Production with 12-15 Tons Per Hour Capacity and Dry Powder Granulation
Working Principle

An electric motor drives the belt, which transmits power to a pair of high-pressure rollers through the reducer. The double rollers interact through relative work - SDZ-I models use open gear interaction, while SDZ-II models are directly driven by discharge axes on a special reducer for extrusion molding.

Raw material enters the hopper and is extruded and molded through the high-pressure roller body. The material then flows to the break molding workshop below the roller body. The crushing motion is driven by chain transmission from the active roller shaft to breaking rollers, which sieve the material in the workroom. Finished particles exit the machine through the screener to the discharge slot.

Double Roller Granulator for NPK Compound Fertilizer Production with 12-15 Tons Per Hour Capacity and Dry Powder Granulation
Applicable Materials
  • Nitrogen fertilizers: Ammonium chloride, ammonium sulfate, ammonium sulphate
  • Potassic fertilizers: Potassium sulfate, potassium chloride, plant ash
  • Phosphate fertilizer: Superphosphate, triple superphosphate, calcium magnesium phosphate
Key Advantages
  • Energy Saving: Normal temperature granulating eliminates the need for drying granules
  • Self-Cleaning Devices: Prevents material adhesion to roller sheets during operation
  • Mixing Devices: Feeding port equipped with mixing mechanisms for uniform material feeding
  • Durable Rollers: Forged from special materials, machined with numerical lathe and milling for rust resistance, acid/alkali resistance, and long service life
  • Dual-Input Power Transmission: Improved power input ratio
  • Multiple Granule Options: Customizable ball socket shapes including pillow, semicircle, stick, pill, walnut, flat ball, and square bar shapes
  • Compact & Stable: Good stability, excellent sealing, low noise, and convenient operation and maintenance
  • Quality Components: Premium bearings and motor for reliable performance
