Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter
Specifications
Brand Name :
diaozhuo
Model Number :
DZ-CSA
Certification :
CE ISO BV SGS
Place of Origin :
ANPING,CHINA
MOQ :
1
Price :
4000-4200usd
Payment Terms :
L/C, D/A, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1set per 20 days
Delivery Time :
20 days
Packaging Details :
pallet
TYPE :
CS-A
SPEED :
70-75KG/H
Volum :
3m³
Packing :
pallet
weight :
1500kg
Description

barbed wire application:

Widely used in military field,Prisons,Detention houses, Government Buildings, National Security Facilities.
Fencing of Residences,Villa Wall and Windows,Express Way,Railway,National Border Lines.It is also used for grassland border, railway, highway isolation protection, etc.

Technical Parameters

item CS-A double twist
motor 3kw
rated output 70kg/h
weight 1500kg
overall dimension 1900*1300*980mm
wire collection part size 1800*750*750mm
barb pitch spacing 76mm 102mm
twist 4
strand diameter 2.2-2.8mm
wire diameter 1.8-2.2mm
rotating speed of drive shaft 432r/min

Barbed Wire Materials For The Machine
1.Electric galvanized wire
2.Hot dipped galvanized wire
3.PVC Coated wire
4.Stainless steel wire

Double Strand Twisted Barbed Wire Making Machine 1.8-2.2mm Diameter

Our Service

1)Machine Warranty: three Year.
2)Enough spare parts of machines could be supplied.
3)Factory Own Designing and Inspection Team.
4)All machines were tested and adjusted before delivery.
5)Engineers avaliable to service machinery overseas: Worker-training, installation.etc.
6)24 hours technical support by e-mail or calling service.
