DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P
DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P
DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P
DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P
Specifications
Brand Name :
FEEO
Model Number :
dc spd
Certification :
CE TUV
Place of Origin :
CHINA
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Western Union, MoneyGram
Delivery Time :
15work days
Code :
FSP-D40
Pole :
2P/3P
In(8/20)us(KA) :
20KA
Imax(8/20)us(KA) :
40KA
Standard :
IEC/EN61643
Type :
II
Characteristic Curve :
B,C,D
Protection Degree :
IP20
Description

Surge Arrester Features:

  • Indicator window is obvious (green is OK, red indicates failure)
    2. Fully enclosed terminal
    3. The shell is made of PC flame retardant material, fire insulation
    4. Replaceable module

Surge Arrester Package:

Standard export carton packing:
2P DC SPD 72pcs/ctn
3P DC SPD 48pcs/ctn
Carton Size 48*29.5*15.2CM3
G.W./N.W.: 20.7/20.1kgs

Surge Arrester Parameters:

tem Surge Arrester
Code FSP-D40
Pole 2P 3P
Voltage 600VDC/ 800VDC 1000VDC-/1500VDC
In(8/20)us(KA) 20KA
CCC 40KA
Standard IEC/EN61643
Type II
Characteristic Curve B,C,D
Working Temperature -5 to +40
C IP20
Electrical life More than 8000times
Mechanical life More than 2000times
Dimension(W)X(H)X(D) 35x90x49 53x90x49
Installation 35MM DIN RAIL

DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P

DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P

DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P

DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P

DC SPD 40KA 1000V Solar Photovoltaic DC Surge Protector IP20 3P
