Specifications
Brand Name :
Strongwin
Model Number :
SZLH320 Feed Plant
Certification :
CE,ISO,SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 sets per year
Delivery Time :
15-30 working days after deposit
Packaging Details :
Wooden Case or In Container
Name :
Poultry Pigeon Chicken Bird Pellet Production Plant
Final pellet :
1.5-15mm
Yield :
2-4T/H
Power :
100KW
Main machine :
crusher,mixer,pellet,cooler,screener machine
Application :
Chicken bird Feed
Description

100KW Poultry Pigeon Chicken Bird Pellet Production Plant

Features of SZLH320 Feed pellet production plant

1, Ring die SZLH320 pellet machine model can improve the production capacity.
2, Adopts high accuracy gearbox for high efficiency.
3, Stainless steel conditioner can ensure the high quality of pellet feed.
4, Main machine use Siemens motor, SKF bearing
5, High output, low noise, compact structure, convenient operation and maintenance.

Technical Parameters of SZLH320 type Feed pellet production plant

Item Name Type Qty Power (KW)
Part 1. Raw material receiving& crushing system
1 Grass crusher FSP500B-22 1 22
1-103 Impulse Filter TBGM20 1
1-105 Bucket Elevator TDTG36/23 1 4
1-106 Cylinder Filtering Sieve TCQY63 1 0.75
1-107 Additive Blender TCXT20 1
1-110 Impeller speed regulating Feeder SWLY60 1 1.1
1-111 Crusher SFSP66*60 1 55
1-114 Impulse Filter TBLMa24 1
1-116 Wind-shielding Screw conveyor TLSB20 1 2.2
Part 2. Mixing System
2-202 Bucket Elevator TDTG36/23 1 4
2-203 Powder Screener SCQZ60 1 5.5
2-207 Feeder for additive 1
2-208 Mixer SLHS1.0 1 11
2-210 Scraper Conveyor TGSU20 1 3
Part 3. pelleting system
3-308 Pellet Mill SZLH350 1 57.95
3-310 Cooler SKLN3 1 1.5
Part 4. Packing system
4-401 Bucket elevator TDTG36/18 1 3
4-402 Rotary Screener SFJH80*2d 1 2.2
4-409 Auto Packing Scale 10-50KG 1 1.5
4-410 Stitch conveyor 1 1.5
Part 5. Auxiliary Equipment System
5-506 Steam Supplying System 1
5-507 Oil adding System 1 2.2
5-508 Oil Adding Tube 1
5-509 Calabash Crane 1 3
