Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
Specifications
Brand Name :
OHMALLOY
Model Number :
N6(99,6%)
Certification :
ISO,Rohs
Place of Origin :
China(Shanghai)
MOQ :
20
Price :
negotiable
Packaging Details :
in roll and woodencase outside
Thickness :
0.005mm~3mm
Width :
3mm~1200mm
Ni(Min) :
99.6&
Surface :
Bright,Soft
Alloy Or Not :
Not
Shape :
Strip
Description

Ni200 Ni201 N4 N6 Pure nickel foil 0.15x41.5mm

Specification:

Item name: Nickel foil/coil/stip

Material : Nickel

Grade: N200, N201, N4, N6

Standard: ASTM, GB

Thickness: 0.005mm-3.0mm

Width:3mm～1200mm

Length & Width: Customized

Chemical composition:

Grade Ni+Co Cu Si Mn C Mg S Fe Total impurities
Max(%) Min(%)
N4 99.9 0.015 0.03 0.002 0.01 0.01 0.001 0.04 0.1
N6 99.5 0.06 0.01 0.05 0.05 0.10 0.005 0.10 0.5

Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright SurfaceNi200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface

Except pure nickel strip, we also can supply the nickel plated steel strip, this kind of strip can be used for battery with low power and low current. The main advantage of this strip is the price, it is lower a lot than pure nickel strip.

Our Nickel plated steel strip’s normal thickness is as follows:
Thickness: 0.08mm, 0.09mm, 0.10mm, 0.12mm, 0.15mm, 0.17mm, 0.20mm, 0.25mm and others.
Width: 3mm to 20mm

How to distinguish the pure nickel strip with nickel plated strip?

Many clients want to buy the pure nickel strip in low price, but sometimes they can be cheated by supplier who use the nickel plated steel strip to instead of pure nickel strip.

So how to check the quality for each strip become very important. It is impossible for us to check the strip by eye or measurement. The simplest way to distinguish is as follows:

Step 1: Cut the strip into pieces

Step 2: Put the piece into 20% hydrochloric acid and wait

Step 3: After few minutes, if the piece have visible reaction, the material should be nickel plated steel strip.

Application of nickel plated steel strip: battery cell connector, assembled battery, MP3, electrical bicycle, digital camera, laptop, power battery, electric vacuum, special bulb.....
Ni200 Ni201 Pure Nickel Foil 0.15x41.5mm Bright Surface
