Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
Specifications
Brand Name :
OHMALLOY/OEM
Model Number :
SP-K-FA-FA-0.3-ANSI
Certification :
Rohs
Place of Origin :
China
MOQ :
500 meters
Payment Terms :
L/C, T/T, , MoneyGram,Paypal
Supply Ability :
500000 meters per month
Delivery Time :
3-8 working days
Packaging Details :
Coil+ Paper Carton；Plywood spool+ plywood Case
Name :
Ultra Thin Thermocouple Type K Cable Alumel Chromel FEP PFA Insulated
Type :
KX
Conductor Material :
+ Chromel -Alumel
Conductor Size :
Customized
Insulation Material :
PFA FEP Fiberglass
Accuracy :
Class I(0~200 Degree Celsius)
Outer diameter :
Customized as customer requirement
Insulation Testing :
OK
Description

Ultra Thin Thermocouple Type K Cable Alumel Chromel FEP PFA Insulated

OHMALLOY cable factory have 30 years in producing the thermocouple extension or compensation cable. We use our own thermocouple conductor to produce all kinds of insulated thermocouple wire and cable, Resistance Temperature Detector (RTD) cables. Working temperature range is -60℃ to +1100℃. According to customer request, we supply professional wire and cable solution.

Now OHMALLOY have all processing matching for braiding, extruding, wrapping, varnishing.... So we can make all cable with all insulation such as PVC, PTFE, Silicone rubber, fiberglass,

The MOQ for fiberglass insulated wire can be any length, even 5meters is ok.

For the insulation such as PVC, , we can supply 500meters as MOQ. That can help many customers on trial stage.

Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision

Chemical Composition

Material Chemical composition (%)
Ni Cr Si Mn Al
KP(Chromel) 90 10
KN(Alumel) 95 1-2 0.5-1.5 1-1.5

Package Reference

Ultra Thin K Thermocouple Wire Customized Conductor Size High Precision
