0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
Specifications
Brand Name :
OHMALLOY
Model Number :
C75200
Certification :
ISO ROHS
Place of Origin :
China(Shanghai)
MOQ :
50kg
Price :
negotiable
Payment Terms :
, L/C, T/T
Supply Ability :
20000T/Year
Delivery Time :
7-20days after your deposit received
Packaging Details :
IN Wooden box
Standard :
ASTM B122
Surface :
Bright
Size :
0.038mm*50mm
Power or not :
Not
Type :
Cu-Ni-Zn
Craft :
Hot forging& Cold Rolling
Shape :
Foil&Strip
JIS :
C7521
Cu :
Min63
UNS :
CuNi18Zn20
Description

0.038mm*50mm Copper-Nickel-Zinc alloy C7521 Strip for Electrostatic plate of EHV Transformer

Description:

C7521 is Copper-Nickel-Zinc alloy, also called nickel silver, German silver, new silver, nickel brass, albata, or electrum, is a copper alloy with nickel and often zinc. Nickel silver is named for its silvery appearance, but it contains no elemental silver unless plated.

The equivalent for C7521 in other countries is C76400,CDA764, CuNi18Zn20,JIS C7521,BZn18-20,NS 106,CW 409 J

Symbol or Brands Temper Tension test Hardness test Chemical Composition
GB JIS UNS Thickness mm Tensile strength MPa Elongation% Thickness mm Vickers Hardness HV Cu Ni Zn
Bzn18-18 C7521 C75200 0 0.08-10.0 ≥375 ≥20 63.5-66.5 16.5-19.5 Balance
1/2H 0.08-10.0 440-570 ≥5 ≥0.06 120-180
H 0.08-10.0 ≥540 ≥3 ≥0.06 150-200

Features:

1) Good color
2) High toughness
3) High strength
4) High stability
5) Excellent elasticity with fine silver gloss
6) Good fatigue
7) Rust and corrosion resistance properties
8) C7521 and C7701 have very good deep-drawing performance

Main application:

Copper-nickel-zinc alloy strip is widely used in antenna, cellphone shielding case,crystal resonator shell, silverware, jewelry, glasses, medical apparatus and instruments, zipper and keys’ industry.

0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna
0.038mm*50mm C7521 Copper Nickel Zinc Alloy For Antenna

FAQ

1. What's the minimum quantity customer can order?

If we have your size in stock, we can provide any quantity you want.

If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.

2. How can you pay for small sample amount?

We have account, wire transfer for sample amount also ok.

3. Customer do not have express account. How will us arrange the delivery for sample order?

Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.

4. What's our payment terms?

We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.

5. Do you provide free samples?

If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.

6. What's our working time?

We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
