Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Specifications
Brand Name :
OHMALLOY
Model Number :
SP-inconel625-rod
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
50KG
Price :
USD 26-35/KG
Payment Terms :
L/C, T/T, , Paypal
Supply Ability :
30000 KG per month
Delivery Time :
5-18 working days after payment confirmed
Packaging Details :
Bag+plywood case
Name :
Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
Material :
Inconel625 NiCr22Mo9Nb
State :
Rod
Surface Treatment :
Polished Bright
Length :
1 meter/1.5 meter/2 meter(or customized)
Warrenty :
3 Years
Description

Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar

Inconel625 has excellent corrosion resistanceat elevated and ambient temperatures,excellent resistance of the inorganic acid corrosion performance,excellent resistance of pitting and crevice corrosion,good machining and welding.

Inconel625 is widely used in following field:

1)Marine Industries: it is used in sea-water for local mechanical stress attach.

2)Aerospace Industries.

3)Chemical Processing:the organic chemical process parts contains chloride,the digester and bleacherin the use of paper pulp and paper making industry,the equipment and parts in the use of acidic gas environments,acetic acid and anhydride reaction generator,sulfur acid cooling

4)Nuclear engineering:nuclear reactors

5)Pollution Control:Absorption tower, re-heater,gas import board, fan, blender, fair water fin, flue and so on.

Chemical Composition(%)

Alloy % Ni Cr Mo Nb+N Fe Al Ti C Mn Si Cu P S

Inconel

625

 Min. 58 20 8 3.15
Max. 23 10 4.15 5 0.4 0.4 0.1 0.5 0.5 0.5 0.015 0.015

Mechanical Properties

Aolly state Tensile strength
Rm N/mm²		 Yield strength
R P 0.2N/mm²		 Elongation
A 5 %		 Brinell hardness
HB		 Density
g/cm³

Melting Point

°C
625 760 345 30 ≤220 8.4

1290-1350

Inconel625 NiCr22Mo9Nb Rod High Temperature Corrosion Resistance Alloy Bar
